S42N11S15N Eaton Industrial Automation Components

Name: S42N11S15N
Brand: Eaton

Part#:S42N11S15N

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

S42N11S15N Eaton - General-Purpose Encapsulated Transformer, EP, Single-phase, PV: 2400V, Taps: None, SV: 120/240V, 115°C, 15 kVA, Al windings, Frame: 182, Indoor-Outdoor

Product Details

Length
14.12 inches
Enclosure
3R
Voltage
2400 volts
Number of Phases
1
Coil Material
Aluminum
Type
Encapsulated Transformer, General Purpose
Secondary Voltage
240 volts
Height
23.31 inches
Frame
182
Weight
289 pounds

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
