SVX03014BAK1K3L2PG Eaton Industrial Automation Components

Name: SVX03014BAK1K3L2PG
Brand: Eaton

SVX03014BAK1K3L2PG on Powermatic Associates

Part#:SVX03014BAK1K3L2PG

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Eaton - SVX03014BAK1K3L2PG

Product Details

IP Rating
IP21
Amperage
46 amperes
Voltage
480 volts
NEMA
1
Enclosure
NEMA 1
Horsepower
30 horse power
Frame
6
Display Type
Bypass Pilot Lights For RA, RB Bypass Options
Height
90 inches
Length
26 inches
Weight
1500 pounds
Width
30 inches

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
