548520 Eriflex Insulators

548520 on Powermatic Associates
Eriflex

Part#:548520

Alt. Part#:ISOTP40M10

Manufacturer:Eriflex

Category:Insulators

Product Lifecycle:Active

Product description

548520 Erico - Low Voltage Metric Insulator, F-F, ISO TP 40M10, Height: 1.57", Depth: 2.09", Diameter: 1.57", Thread size: M10, Static load: 2473lb

Product Details

  • Height
    1.57 in
  • Thread Size
    M10

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


About the product

548520 Erico - Low Voltage Metric Insulator: Reliable, Durable, and Safe

The 548520 Erico Low Voltage Metric Insulator is a high-quality insulating solution designed for demanding electrical applications. Built for superior performance and reliability, this insulator is ideal for industrial and commercial systems that require excellent mechanical support and dielectric strength.

Key Features

Halogen-Free Design: Ensures safer use by minimizing toxic emissions during high-temperature conditions.

High Resistance to Leakage Current: Protects electrical systems and enhances operational reliability.

Stable Electrical and Mechanical Performance: Delivers consistent and dependable results under varying conditions.

Fiberglass-Reinforced Construction: Combines lightweight materials with exceptional strength and durability.

UL® Recognized Certification: Meets E125470 standards with dielectric withstand rating up to 1,500 VAC/DC.

RoHS Compliant: Environmentally responsible construction meets global safety standards.

Specifications

Dielectric Strength: UL 1,500

Finish: Electrogalvanized for outstanding corrosion resistance

Material: Steel with Glass Fiber Reinforced Polyamide for enhanced performance and longevity

Compliance: IEC® 60695-2-11 Glow Wire Test at 960 °C for fire safety

Flammability Rating: UL® 94V-0, ensuring reduced fire risks

Working Temperature Range: -40°F to 266°F for performance in extreme conditions

Dimensions:

Height: 1.57"

Depth: 2.09"

Diameter: 1.57"

Thread Size: M10

Static Load Capacity: Supports up to 2,473 lbs.

Why Choose the Erico 548520 Metric Insulator?

The 548520 insulator is engineered for heavy-duty applications where superior insulation and mechanical stability are critical. Its halogen-free, RoHS-compliant design ensures safety and sustainability, while the fiberglass reinforcement and electrogalvanized finish provide exceptional durability and resistance to wear and corrosion.

Applications

Low-voltage electrical installations

Industrial mac
