1709136 Festo Pneumatic Components
Part#:1709136
Alt. Part#:PREL-90-HP3-A4-A-20CFX-S1-4
Manufacturer:Festo
Category:Pneumatic Components
Product Lifecycle:Active
Product description
electrical pressure regulator PREL-90-HP3-A4-A-20CFX-S1-4 Size: 90, Nominal diameter DN: 24, Series: L, Assembly position: Vertical, Type of actuation: electrical
Product Details
- Size 90
- Symbol 00995417
- Analog output signal range 4 - 20 mA
- Storage temperature -10 °C ... 60 °C
- Certification Special Equipment Type Test Certification
- Controller function Outlet pressure constant With secondary exhausting
- Nominal operating voltage DC 24 V
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas
- Temperature of medium 5 °C ... 50 °C
- Electrical connection IN Plug, M12, 5-pin, A-coded
- Pneumatic connection 11 G1/4
- Pneumatic connection 82 G3/8
- Type code PREL
- Series L
- Design Electrically adjustable pressure regulator
- Pressure regulation range 0.5 bar ... 20 bar
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- LABS-Conformity VDMA24364 zone III
- Mounting position Vertical
- Analog input signal range 4 - 20 mA
- For use in the food industry See supplementary material information
- Electrical connection OUT Plug, M12, 5-pin, A-coded
- Pneumatic connection 2 G1
- Lower cover material Aluminum, anodized
- Nominal width DN 24
- Actuation type Electrical
- Operating pressure 0 MPa ... 5 MPa
- Setpoint/actual values Current type 4–20 mA
- Product weight 6100 g
- Type of mounting Optionally: With accessories
- Pneumatic connection 22 G¼
- Material of spring Spring steel
- Ambient temperature 5 °C ... 50 °C
- Pneumatic connection 1 G1
- Pneumatic connection 3 G1
- Note on materials RoHS-compliant
- Housing material Aluminum, anodized
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
