197016 Festo Directional Control Valves

Product Details

• Valve function
  3/2, closed, monostable
• Width
  10 mm
• Design
  Poppet valve with return spring
• Width dimension
  10 mm
• Mounting position
  Any
• Symbol
  00991308
• Duty cycle
  100%
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• Pneumatic connection 3
  Sub-base
• Seals material
  FPM NBR
• Certificate issuing authority
  UL MH19482
• Operating voltage
  12V DC
• Reset method
  Mechanical spring
• Type of control
  Direct
• On switching time
  4 ms
• Permissible voltage fluctuations
  +/- 10 %
• Vibration resistance
  Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
• Electrical connection
  Plug
• Pneumatic connection 1
  Sub-base
• Lap
  Underlap
Pneumatic working port
M3
Operating pressure
0 bar ... 8 bar
Degree of protection
IP40
Sealing principle
Soft
Manual override
Non-detenting
Note on forced dynamization
Switching frequency at least once a week
Electrical power consumption
1 W
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Ambient temperature
-5 °C ... 40 °C
Housing material
PA-reinforced PPS-reinforced
Actuation type
Electrical
Standard nominal flow rate
10 l/min
Certification
c UL us - Recognized (OL)
Exhaust air function
With flow control option
Valve position ID
Label
Max. switching frequency
20 Hz
Coil characteristics
12 V DC: 1.0 W
Storage temperature
-20 °C ... 60 °C
Temperature of medium
-5 °C ... 40 °C
Type of mounting
On sub-base With through-hole
Nominal width
0.65 mm
Type code
MHP1
Flow direction
Non-reversible
Switching time off
4 ms
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Product weight
10 g
Pneumatic connection 2
M3
Note on materials
Free of copper and PTFE RoHS-compliant
