197052 Festo Directional Control Valves

Product Details

• Standard nominal flow rate
  14 l/min
• Design
  Poppet valve with return spring
• Type code
  MHP1
• Symbol
  00991398
• Suitability for vacuum
  yes
• On switching time
  4 ms
• Permissible voltage fluctuations
  +/- 10 %
• Shock resistance
  Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
• Temperature of medium
  -5 °C ... 40 °C
• Pneumatic connection 2
  M3
• Seals material
  FPM NBR
• Valve function
  2/2, closed, monostable
• Actuation type
  Electrical
• Operating voltage
  12V DC
• Nominal width
  0.9 mm
• Sealing principle
  Soft
• Note on forced dynamization
  Switching frequency at least once a week
• Duty cycle
  100%
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Pneumatic connection 1
  Sub-base
Certificate issuing authority
UL MH19482
Pneumatic working port
M3
Degree of protection
IP40
Certification
c UL us - Recognized (OL)
Exhaust air function
Without flow control option
Manual override
Non-detenting
Switching time off
5 ms
Coil characteristics
12 V DC: 1.0 W
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Ambient temperature
-5 °C ... 40 °C
Electrical connection
Plug
Lap
Underlap
Width
10 mm
Operating pressure
-0.9 bar ... 2 bar
Mounting position
Any
Type of control
Direct
Valve position ID
Label
Electrical power consumption
1 W
Vibration resistance
Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Storage temperature
-20 °C ... 60 °C
Note on materials
Free of copper and PTFE RoHS-compliant
Reset method
Mechanical spring
Width dimension
10 mm
Flow direction
Non-reversible
Max. switching frequency
20 Hz
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Product weight
10 g
Type of mounting
On sub-base With through-hole
Housing material
PA-reinforced PPS-reinforced
