525127 Festo Pneumatic Valves Accessories

525127 on Powermatic Associates
Festo

Part#:525127

Alt. Part#:MHA2-PR2-5-M5

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

manifold block MHA2-PR2-5-M5 for manifold block valves MHA2-...-HC/TC Max. number of valve positions: 2, Corrosion resistance classification CRC: 2 - Moderate corrosion stress, Product weight: 254 g, Mounting method for sub-base: (* with through hole, * w

Product Details

  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Pneumatic valve mounting type
    With internal thread
  • Pneumatic connection 4
    M5
  • Pneumatic connection 3
    M7
  • Product weight
    254 g
  • Pneumatic connection 2
    M5
  • Pneumatic connection 5
    M7
  • Type code
    MH2
  • Sub-base mounting type
    With through-hole With H-rail
  • Material of sub-base
    Wrought aluminum alloy
  • Max. no. of valve positions
    2
  • Pneumatic connection 1
    M7
  • Note on materials
    Free of copper and PTFE

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
