550243 Festo Directional Control Valves

Product Details

• Actuation type
  Electrical
• Pneumatic working port
  G1/8
• Design
  Piston gate valve
• Type of control
  Pilot-controlled
• On switching time
  20 ms
• Reset method
  Mechanical spring
• Sealing principle
  Soft
• Mounting position
  Any
• Flow direction
  Non-reversible
• Information on operating and pilot media
  Operation with oil lubrication possible (required for further use)
• Max. tightening torque plug
  0.4 Nm
• Pilot air port 14
  M3
• Note on materials
  RoHS-compliant
• Lap
  Overlap
• Standard nominal flow rate
  700 l/min
• Degree of protection
  IP65 as per IEC 60529
• Manual override
  Detenting via accessory Non-detenting
• Symbol
  00991036
• Switching time off
  42 ms
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
Ambient temperature
-5 °C ... 50 °C
Pneumatic connection 1
G1/8
Housing material
Die-cast aluminum
Maritime classification
See certificate
Operating pressure
3 bar ... 8 bar
Nominal width
6 mm
Exhaust air function
With flow control option
Valve position ID
Label holder
Coil characteristics
24 V DC: 1.28 W
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Electrical connection
4-pin M8x1
Pilot air port 12
M3
Pneumatic connection 4
G1/8
Valve function
5/3, exhausted
Width
14 mm
Operating voltage
24V DC
Type code
CPE14
Pilot air supply port
Internal
Duty cycle
100%
Max. positive test pulse with 0 signal
1200 µs
Vibration resistance
Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
Product weight
120 g
Pilot exhaust air port 82
M3
Type of mounting
With through-hole
Pneumatic connection 5
G1/8
Max. negative test pulse on 1 signal
900 µs
Permissible voltage fluctuations
-15 % / +10 %
Temperature of medium
-5 °C ... 50 °C
Pilot exhaust air port 84
M3
Pneumatic connection 3
G1/8
Pneumatic connection 2
G1/8
Seals material
NBR
