550604 Festo Pneumatic Valves Accessories

550604 on Powermatic Associates
Festo

Part#:550604

Alt. Part#:CPE10-3/2-PRS-1/4-5-NPT

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

manifold block CPE10-3/2-PRS-1/4-5-NPT For CPE valves. Grid dimension: 16 mm, Assembly position: Any, Max. number of valve positions: 5, Max. no. of pressure zones: 2, Operating pressure: -13 - 145 Psi

Product Details

  • Ambient temperature
    -5 °C ... 50 °C
  • Note on materials
    RoHS-compliant
  • Mounting position
    Any
  • Corrosion resistance class (CRC)
    2 - Moderate corrosion stress
  • Manifold block type of mounting
    With through-hole
  • Pneumatic connection 5
    1/4 NPT
  • Max. no. of valve positions
    5
  • Temperature of medium
    -5 °C ... 50 °C
  • Pneumatic valve mounting type
    With internal thread
  • Manifold rail material
    Wrought aluminum alloy
  • Width dimension
    16 mm
  • Max. no. of pressure zones
    2
  • Max. tightening torque for valve mounting
    1.22 Nm
  • Pneumatic connection 1
    1/4 NPT
  • Type code
    CPE10-PRS
  • Operating pressure
    -0.896 bar ... 9.997 bar
  • Product weight
    235.163 g
  • Pneumatic connection 3
    1/4 NPT

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

550604 Related Documents

550604 DataSheet.pdf
