553575 Festo Cable Assemblies
Part#:553575
Alt. Part#:NEBV-M12G8-K-2-M12G4
Manufacturer:Festo
Category:Cable Assemblies
Product Lifecycle:Active
Product description
connecting cable NEBV-M12G8-K-2-M12G4 Conforms to standard: EN 61076-2-101, Cable identification: Without inscription label holder, Electrical connection 1, function: Field device side, Electrical connection 1, design: Round, Electrical connection 1, conn
Product Details
- Type code NEBV
- Cable designation Without label holder
- Electrical connection 1, connection technology M12x1 A-coded as per EN 61076-2-101
- Electrical connection for input 1, connection pattern 00992265
- Electrical connection 2, occupied pins/wires 4
- Electrical connection 2, connection pattern 00995386
- Bending radius, flexible cable installation ≥ 58 mm
- Ambient temperature -25 °C ... 85 °C
- Material of cable sheath TPE-U(PUR)
- Material of pin contacts Brass, gold-plated
- Electrical connection 1, occupied pins/wires 4
- Electrical connection 2, cable outlet Straight
- Electrical connection 2, function Control side
- Electrical connection 2, type of mounting Screw-type lock
- Cable length 2 m
- Bending radius, fixed cable installation ≥ 29 mm
- Degree of protection IP67
- Ambient temperature with flexible cable installation -5 °C ... 80 °C
- Contamination level 3
- Material of screw-type lock Brass, nickel-plated
- Seals material NBR
- Electrical connection 1, function Field device end
- Electrical connection 1, design Round
- Electrical connection 1, connection type Socket
- Electrical connection 1, type of mounting Screw-type lock
- Electrical connection 2, number of pins/wires 4
- Surge resistance 0.8 kV
- Cable diameter tolerance ± 0.2 mm
- CE marking (see declaration of conformity) As per EU EMC directive
- Housing colour Black
- Electrical connection 2, design Round
- DC operating voltage range 0 V ... 30 V
- Cable characteristic Standard
- Cable design 4 x 0.34 mm² Shielded
- Nominal conductor cross section 0.34 mm²
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Color cable sheath Gray
- Conforms to standard EN 61076-2-101
- Electrical connection 1, cable outlet Straight
- Electrical connection 1, number of pins/wires 8
- Electrical connection 2, connection type Plug
- Electrical connection 2, connection technology M12x1 A-coded as per EN 61076-2-101
- Operating voltage range AC 0 V ... 30 V
- Current rating at 40°C 2 A
- Cable diameter 5.6 mm
- Note on degree of protection In mounted state
- Note on materials RoHS-compliant Halogen-free
- Housing material TPE-U(PUR)
- Insulating sheath material PP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
