560217 Festo Pneumatic Grippers

Product Details

• Max. interchangeability
  ≤ 0.2 mm
• Type code
  HGPT
• Mode of operation
  Double-acting
• Max. operating frequency of pneumatic gripper
  ≤ 2 Hz
• Min. opening time at 6 bar
  67 ms
• Maximum torque on gripper jaw, Mx static
  100 Nm
• Product weight
  1075 g
• Pneumatic connection
  M5
• Max. gripper jaw angular play ax, ay
  ≤ 0.1 deg
• Number of gripper jaws
  2
• Gripping force backup
  On opening
• Operating pressure for sealing air
  0 bar ... 0.5 bar
• Rotational symmetry
  ≤ 0.2 mm
• Gripper function
  Parallel
• Operating pressure
  4 bar ... 8 bar
• Symbol
  00995947
• Degree of protection
  IP40
• Mass moment of inertia
  10.99 kgcm²
• Stroke per gripper jaw
  10 mm
• Pneumatic gripper repetition accuracy
  ≤ 0.05 mm
Design
Inclined plane Positively driven motion sequence
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Maximum force on gripper jaw Fz, static
2500 N
Relubrication interval for guidance elements
5 MioCyc
Housing material
Aluminum Anodized
Size
40
Max. gripper jaw backlash Sz
≤ 0.02 mm
Mounting position
Any
Position sensing
For proximity sensor
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Max. mass per external gripper finger
310 g
Min. closing time at 6 bar
135 ms
Ambient temperature
5 °C ... 60 °C
Maximum torque on gripper jaw, My static
90 Nm
Type of mounting
Optionally: With internal thread and dowel pin
Note on materials
Free of copper and PTFE RoHS-compliant
Gripper jaw material
Steel Hardened
Maximum torque on gripper jaw, Mz static
75 Nm
Cover cap material
High-alloy stainless steel
Sealing air pneumatic connection
M5
