566725 Festo Pneumatic Valves Accessories

566725 on Powermatic Associates
Festo

Part#:566725

Alt. Part#:VAVE-L1-1VL4-LP

Manufacturer:Festo

Category:Pneumatic Valves Accessories

Product Lifecycle:Active

Product description

electrical connection box VAVE-L1-1VL4-LP Polarity protected: Bipolar, Additional functions: Spark arresting, Signal status display: LED, Nominal operating voltage DC: (* 12 V, * 24 V), Surge strength: 0,8 kV

Product Details

  • Surge resistance
    0.8 kV
  • Additional functions
    Spark suppression
  • Ambient temperature
    -5 °C ... 50 °C
  • Cable length
    5 m
  • Note on materials
    RoHS-compliant
  • Mounting position
    Any
  • Nominal operating voltage DC
    12 V 24 V
  • Extended ambient temperature
    -5 - 60 °C
  • Type of mounting
    Clip
  • Type code
    VAVE
  • Signal status display
    LED
  • Product weight
    33.5 g
  • Protective earth connection
    Not available
  • Housing material
    PA
  • Corrosion resistance class (CRC)
    0 - No corrosion stress
  • Connection cross section
    0.14 mm²
  • Housing colour
    Black
  • Contamination level
    3
  • Reverse polarity protection
    Bipolar
  • Degree of protection
    IP40
  • Electrical connection
    Flying lead

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
