573215 Festo Directional Control Valves

Product Details

• Valve function
  3/2, closed, monostable
• Type code
  VSCS
• Width
  15 mm
• Operating pressure
  0 bar ... 10 bar
• Certification
  c UL us - Recognized (OL)
• Conforms to standard
  ISO 15218
• Switching time off
  6 ms
• Permissible voltage fluctuations
  -15 % / +10 %
• Vibration resistance
  Transport application test with severity level 2 as per FN 942017-4 and EN 60068-2-6
• Lap
  Underlap
• Standard nominal flow rate
  18 l/min
• Sealing principle
  Soft
• Type of control
  Direct
• On switching time
  6 ms
• Operating medium
  Compressed air as per ISO 8573-1:2010 [7:4:4]
• Corrosion resistance class (CRC)
  2 - Moderate corrosion stress
• Pneumatic connection 2
  Sub-base
• Operating voltage
  24V DC
• Degree of protection
  IP65
• Mounting position
  Any
Symbol
00991308
Note on forced dynamization
Switching frequency at least once a week
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
Temperature of medium
-10 °C ... 50 °C
Pneumatic connection 3
Sub-base
Actuation type
Electrical
Pneumatic working port
Sub-base, size 15 mm as per ISO 15218
Reset method
Mechanical spring
Flow direction
Non-reversible
Duty cycle
100%
Coil characteristics
24 V DC: 1.8 W
Electrical connection
M12x1 as per IEC 61076-2-101
Manual override
Detenting Non-detenting
Max. positive test pulse with 0 signal
1800 µs
Max. negative test pulse on 1 signal
800 µs
Shock resistance
Shock test with severity level 2 as per FN 942017-5 and EN 60068-2-27
Pneumatic connection 1
Sub-base
Seals material
NBR
Ambient temperature
-10 °C ... 50 °C
Note on materials
RoHS-compliant
