573809 Festo Directional Control Valves
Part#:573809
Alt. Part#:VUWG-L10-B52-M5
Manufacturer:Festo
Category:Directional Control Valves
Product Lifecycle:Active
Product description
pneumatic valve VUWG-L10-B52-M5 Valve function: 5/2 bistable, Type of actuation: pneumatic, Valve size: 10 mm, Standard nominal flow rate: 220 l/min, Operating pressure: -0,9 - 10 bar
Product Details
- Lap Overlap
- Standard nominal flow rate 220 l/min
- Width dimension 10.5 mm
- Sealing principle Soft
- Type of control Direct
- Symbol 00991037
- Temperature of medium -5 °C ... 50 °C
- Ambient temperature -5 °C ... 60 °C
- Pneumatic connection 1 M5
- Pneumatic connection 3 M5
- Type of mounting Optionally: With through-hole
- Pneumatic connection 4 M5
- Note on materials RoHS-compliant
- Valve size 10 mm
- Type code VUWG
- Manual override None
- Suitability for vacuum yes
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Corrosion resistance class (CRC) 2 - Moderate corrosion stress
- Pilot medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Pilot air port 14 M5
- Pneumatic connection 5 M5
- Actuation type Pneumatic
- Operating pressure -0.9 bar ... 10 bar
- Design Piston gate valve
- Mounting position Any
- Flow direction Reversible
- Changeover time 5 ms
- Pneumatic connection 2 M5
- Housing material Aluminum Anodized
- Valve function 5/2, bistable
- Pneumatic working port M5
- Exhaust air function With flow control option
- Pilot pressure 1.5 bar ... 10 bar
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Product weight 48 g
- Pilot air port 12 M5
- Seals material HNBR NBR
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
