578324 Festo Pneumatic Components
Part#:578324
Alt. Part#:NPQH-D-Q6-E-P10
Manufacturer:Festo
Category:Pneumatic Components
Product Lifecycle:Active
Product description
plug connector NPQH-D-Q6-E-P10 Size: Standard, Nominal size: 5 mm, Assembly position: Any, Container size: 10, Design structure: Push/pull principle
Product Details
- Operating pressure for entire temperature range -0.95 bar ... 20 bar
- Product weight 15.1 g
- Pack size 10
- Ambient temperature 0 °C ... 150 °C
- Housing material Brass, nickel-plated
- Size Standard
- Type code NPQH
- Information on operating and pilot media Operation with oil lubrication possible
- Operating medium Compressed air as per ISO 8573-1:2010 [7:-:-] Water as per manufacturer's declaration at www.festo.com
- Pneumatic connection 2 for pneumatic tubing outside diameter 6 mm
- Material of tube retaining claw High-alloy stainless steel
- Nominal width 5 mm
- Design Push-pull principle
- Pneumatic connection 1 For pneumatic tubing outside diameter 6 mm
- Releasing ring material Brass, nickel-plated
- Certificate issuing authority NSF C0523185
- Mounting position Any
- Corrosion resistance class (CRC) 3 - High corrosion stress
- For use in the food industry See declaration of conformity NSF/ANSI 169
- Note on materials RoHS-compliant
- Material of tubing seal FPM
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
