8093271 Festo Cable Assemblies
Part#:8093271
Alt. Part#:NEBC-U7G10-EH-15-N-S-U5G9
Manufacturer:Festo
Category:Cable Assemblies
Product Lifecycle:Active
Product description
connecting cable NEBC-U7G10-EH-15-N-S-U5G9 Additional functions: Hybrid cable, Cable identification: Without inscription label holder, Product weight: 444 g, Electrical connection 1, function: Field device side, Electrical connection 1, design: Angular
Product Details
- Electrical connection 1, function Field device end
- Electrical connection 1, number of pins/wires 10
- Electrical connection 1, type of mounting 2x screw, M2x0.4
- Electrical connection 2, number of pins/wires 9
- Cable length 15 m
- Note on degree of protection In mounted state
- Contamination level 1
- Corrosion resistance class (CRC) 0 - No corrosion stress
- Cable designation Without label holder
- Electrical connection 1, cable outlet Straight
- Electrical connection 2, function Control side
- Electrical connection 2, cable outlet Straight
- Electrical connection 2, connection pattern 00995730
- Current rating at 40°C 0.9 A
- Degree of protection IP20
- Note on materials Contains paint-wetting impairment substances RoHS-compliant
- Additional functions Hybrid cable
- Electrical connection 1, design Rectangular
- Electrical connection 1, occupied pins/wires 9
- Electrical connection 2, design Rectangular
- DC operating voltage range 4.75 V ... 5.25 V
- Bending radius, fixed cable installation ≥ 20 mm
- Ambient temperature -5 °C ... 50 °C
- Ambient temperature with flexible cable installation -5 °C ... 50 °C
- Color cable sheath Black
- Product weight 444 g
- Electrical connection for input 1, connection pattern 00995732
- Electrical connection 2, occupied pins/wires 9
- Electrical connection 2, type of mounting Inserted
- Cable characteristic Suitable for energy chains
- Cable diameter tolerance ± 0.2 mm
- Bending radius, flexible cable installation ≥ 10 mm
- CE marking (see declaration of conformity) As per EU EMC directive
- Material of cable sheath PVC
- Housing colour Silver
- Type code NEBC
- Electrical connection 1, connection type Plug
- Electrical connection 1, connection technology USB 3.0 type B micro
- Electrical connection 2, connection type Plug
- Electrical connection 2, connection technology USB 3.0 type A
- Nominal operating voltage DC 5 V
- Cable diameter 3.1 mm
- Storage temperature -40 °C ... 90 °C
- Housing material Wrought aluminum alloy, anodized
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
