40.51.9.012.0000 Finder Control Relays

40.51.9.012.0000 on Powermatic Associates
Finder

Part#:40.51.9.012.0000

Manufacturer:Finder

Category:Control Relays

Product Lifecycle:Active

Product description

Finder 40.51.9.012.0000 is a relay with a solder pin connection type, designed for a rated current of 12A at 250Vac (AC-1) and 12A at 30Vdc (DC-1), with lower current ratings of 0.6A at 110Vdc and 0.3A at 220Vdc for Normally Open (NO) auxiliary contacts. It operates with a supply voltage of 1C/O / SPDT (Single Pole Double Throw), and is capable of handling ambient air temperatures from -40 to +85 degrees Celsius for both operation and storage. The relay supports a communication protocol of type C, has a net width of 29 mm, and a net depth of 25 mm. It is designed for PCB or plug-in mounting, with a control voltage (AC) of 6 kV, and features a power consumption of 0.65 W. The visual position indicator has a 5.3mm pins pitch, and the relay is rated for 200,000 operations for Normally Closed (NC) circuits and 10,000,000 operations overall. The relay's contacts are made of AgNi (Silver Nickel), ensuring durability and longevity in various applications.

Product Details

  • Primary brand
    Finder
  • Rated power
    1000VA (230Vac; AC-15) 3000VA (250Vac; AC-1) 0.65W
  • Mounting mode
    PCB Plug-in
  • Power consumption
    0.65 W
  • Distance
    5.3mm pins pitch
  • Poles
    1 Pole(s)
  • Ambient air temperature for operation
    -40...+85 °C
  • Rated impulse voltage (Uimp)
    6 kV
  • Net Depth (mm)
    12.4 mm
  • Product series / family name
    40 series
  • Connection type
    Solder pin
  • Degree of protection
    RT II
  • Mechanical durability (at no load)
    10 000 000 operations
  • Net Width (mm)
    29 mm
  • Rated current
    12A (250Vac; AC-1) 12A (30Vdc; DC-1) 0.6A (110Vdc; DC-1) 0.3A (220Vdc; DC-1)
  • Control Voltage (DC)
    12Vdc
  • Compliant with standard(s)
    cURus Lloyd Register (LR) CCC RINA IMQ CSA VDE EAC EN 60335-1 EN 60664-1 EN 60715 EN 61000-4-5 EN 61810-1
  • Contacts coating
    AgNi (Silver Nickel)
  • Main function
    Relay
  • Rated voltage (AC)
    250Vac
  • Contacts type
    1C/O / SPDT (Single Pole Double Throw)
  • Electrical durability (with load)
    200 000 operations
  • Net Height (mm)
    25 mm

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

40.51.9.012.0000 Related Documents

Finder - 40 Series - Catalogue.pdf
