40.52.9.006.0000 Finder Control Relays

40.52.9.006.0000 on Powermatic Associates
Finder

Part#:40.52.9.006.0000

Manufacturer:Finder

Category:Control Relays

Product Lifecycle:Active

Product description

Finder 40.52.9.006.0000 is a relay with solder pin connection type, designed for a rated current of 8A at 250Vac (AC-1) and 8A at 30Vdc (DC-1), with lower current ratings of 0.6A at 110Vdc and 0.3A at 220Vdc for Normally Open (NO) auxiliary contacts. It supports a supply voltage of 2C/O / DPDT (Double Pole Double Throw), with an ambient air temperature for operation at 750VA (230Vac) and for storage at 2000VA (250Vac). The relay operates within an ambient air temperature range of -40 to +85 degrees Celsius and has a control voltage of 6 kV. It features a net width of 25 mm, a net depth of 29 mm, and a power consumption of 0.65 W. The mounting mode is designed for PCB plug-in applications, with a response time of 0.65 W and a visual position indicator of 5.3mm pins pitch. It is rated for 100,000 operations for Normally Closed (NC) circuits and has a durability of 10,000,000 operations. The relay's dimensions include a length of 12.4 mm and a diameter for pin pitch at 5.3mm, designed with AgNi (Silver Nickel) contacts.

Product Details

  • Main function
    Relay
  • Connection type
    Solder pin
  • Distance
    5.3mm pins pitch
  • Poles
    2 Pole(s)
  • Degree of protection
    RT II
  • Electrical durability (with load)
    100 000 operations
  • Net Height (mm)
    25 mm
  • Net Depth (mm)
    12.4 mm
  • Product series / family name
    40 series
  • Rated voltage (AC)
    250Vac
  • Mounting mode
    PCB Plug-in
  • Contacts type
    2C/O / DPDT (Double Pole Double Throw)
  • Mechanical durability (at no load)
    10 000 000 operations
  • Rated current
    8A (250Vac; AC-1) 8A (30Vdc; DC-1) 0.6A (110Vdc; DC-1) 0.3A (220Vdc; DC-1)
  • Control Voltage (DC)
    6Vdc
  • Compliant with standard(s)
    cURus Lloyd Register (LR) CCC RINA IMQ CSA VDE EAC EN 60335-1 EN 60664-1 EN 60715 EN 61000-4-5 EN 61810-1
  • Rated impulse voltage (Uimp)
    6 kV
  • Net Width (mm)
    29 mm
  • Primary brand
    Finder
  • Rated power
    750VA (230Vac; AC-15) 2000VA (250Vac; AC-1) 0.65W
  • Ambient air temperature for operation
    -40...+85 °C
  • Power consumption
    0.65 W
  • Contacts coating
    AgNi (Silver Nickel)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
