DNF18-206FIB-L Panduit Electronic Components

Product Details

• Wire Strip Length (mm)
  7.1
• Finish/Coating
  Tinned
• Maximum Wire Insulation Diameter (In.)
  0.14
• Overall Width (mm)
  7.9
• Minimum Wire Size (AWG)
  #18
• Maximum Voltage (V)
  600
• Insulation Diameter (mm)
  3.5
• Overall Height (mm)
  5.6
• Note
  DNF18-206FIB-L replaces DNF18-206FIB-C
• Tab Size (In.)
  0.21
• Color Code
  Red
• Overall Height (In.)
  0.22
• Product Type
  Loose Piece Disconnect
• Maximum Copper Conductor Size (AWG)
  #22
• Insulation Material
  Nylon - Barrel Insulated
• Insulation Diameter (In.)
  0.14
• Overall Length (In.)
  0.78
• For Use With
  CT-1525, CT-2500 (CT-2520CH), CT-100A, CT-160, CT-260, CT-600A, (CT-520CH)
• Disconnect Type
  Female Disconnect
• Standards Met
  UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153
Maximum Operating Temperature (°C)
105
Overall Width (In.)
0.31
Maximum Voltage (kV)
0.6
Minimum Copper Conductor Size (AWG)
#18
Base Material
Brass
Sub Brand
Pan-Term
Seam Type
Butted
Maximum Wire Size (AWG)
#22
Tab Size (mm)
5.2
Flammability Rating
HB
Overall Length (mm)
19.8
Part Features
• Disconnect can be inserted and removed from the male tab without the use of tools for lower installed cost • Fully insulated design provides protection from electrical shorts • Internal wire stop assures proper length of insertion into terminal barre
Wire Strip Length (In.)
0.28
Maximum Operating Temperature (°F)
221
Maximum Wire Insulation Diameter (mm)
3.6
Packaging Type
Bottle
