FSD75-8-D Panduit Industrial Automation Components

Product Details

• Wire Strip Length (mm)
  11.9
• For Use With
  CT-1160, CT-1170, CT-1090, CT-1002, CT-1003, CT-1123, CP-991, CTFP-25, CTFP-40, CT-2300/ST (CD-090), CT-2500/L (CT-2523CH)
• Note
  UL with 20 AWG wire only
• Inside Diameter (In.)
  0.04
• Overall Length (In.)
  0.53
• Maximum Metric Conductor Size (mm²)
  0.5
• Pin Length (In.)
  0.31
• Finish/Coating
  Tin-Plated
• Flammability Rating
  UL94-HB
• Packaging Type
  Loose Piece Ferrules
• Copper Conductor Size (AWG)
  22 - 20
• Maximum Operating Temperature (°C)
  105
• Maximum Wire Insulation Diameter (mm)
  2.5
• Cover Material
  Polypropylene
• Inside Diameter (mm)
  1.1
• Product Type
  Single wire ferrule
• Base Material
  Copper
• Minimum Metric Conductor Size (mm²)
  0.5
• Minimum Operating Temperature (°C)
  -54
• Overall Length (mm)
  13.5
Ferrule Type
Single Wire Standard
Pin Length (mm)
8
Standards Met
DIN 46228, CSA C22.2 No. 291-14, UL 486F
Maximum Operating Temperature (°F)
221
Maximum Wire Insulation Diameter (In.)
0.09
Sub Brand
Pan-Term®
Wire Strip Length (In.)
15/32
Minimum Operating Temperature (°F)
-60
Color Code
White
Part Features
Polypropylene insulation housing conforms to DIN color requirements Meets DIN, UL and CSA standards for single wire containment Funnel entry for faster insertion and lower installed cost Designed with a seamless barrel to contain loose wire strands for
