PN18-8R-C Panduit Electronic Components

Product Details

• Maximum Copper Conductor Size (AWG SOL)
  #18
• Stud Size
  #8
• Color Code
  Red
• Sub Brand
  Pan-Term®
• Minimum Wire Size (AWG)
  #22
• Standards Met
  UL 486A/B, and CSA 22.2 No.65
• Maximum Operating Temperature (°F)
  221
• Tongue Thickness (In.)
  0.03
• Maximum Metric Conductor Size (mm²)
  1.5
• Maximum Voltage (V)
  600
• Maximum Wire Insulation Diameter (In.)
  0.145
• Tongue Thickness (mm)
  0.8
• Minimum Copper Conductor Size (AWG SOL)
  #22
• Maximum Voltage (kV)
  0.6
• Maximum Wire Insulation Diameter (mm)
  3.68
• Tongue Width (In.)
  0.31
• Maximum Wire Size (AWG)
  #18
• Wire Strip Length (mm)
  5.6
• Flammability Rating
  UL94-HB
• Overall Width (mm)
  7.9
Insulation Material
Nylon
Minimum Metric Conductor Size (mm²)
0.5
Barrel Type
Grip Sleeve
Overall Width (In.)
0.31
For Use With
CT-100, CT-1550, CT-1551, CT-2300/ST (CD-550), CT-2500/L (CT-2550CH), UP14ZLW (CD-550)
Maximum Copper Conductor Size (AWG STR)
#18
Wire Strip Length (In.)
7/32
Finish/Coating
Tin-Plated
Overall Length (In.)
0.85
Minimum Copper Conductor Size (AWG STR)
#22
Base Material
Copper
Maximum Operating Temperature (°C)
105
Overall Length (mm)
21.6
Tongue Width (mm)
7.9
Product Type
Loose Piece Ring Terminal
Part Features
• Ring tongue design assures a secure connection in high vibration applications • Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications • Internal barrel serrations assure goo
Packaging Type
Bottle
