Powermatic Associates Logo

PAXS0000 Red Lion Industrial Automation Components

PAXS0000 on Powermatic Associates
Red Lion

Part#:PAXS0000

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAXS0000 is a dynamometer digital meter designed for strain gauge or load cell measurements. It features a 1/8 DIN (96x48mm) size with 14.2mm red digits and communication capabilities, falling under the PAX series. The dimensions are specified as 1/8 DIN horizontal, measuring W96mm x H48mm (3.80" x 1.95"), and it offers a degree of protection rated at IP65 NEMA 4X. The supply voltage required ranges from 11-36Vdc, accommodating both 12Vdc and 24Vdc systems. It has a 20Hz analog input sampling rate and includes 1 x analog input for -24...+24mV / -240...+240mV strain gauge input DC with 16-bits conversion. Additionally, it features 3 x digital inputs (Sink/Source) for user input and 1 x analog output for retransmission purposes.

Product Details

  • Display
    1 row x 5-digits red characters (14.2mm / 0.56" high) LED display
  • Digital inputs
    3 x digital inputs (Sink/Source) (USER INPUT)
  • Analog outputs
    1 x analog output (retransmission)
  • Degree of protection
    IP65 NEMA 4X
  • Main function
    Dynamometer (Digital)
  • Design
    3 users inputs 1/8 DIN (96x48mm) 14.2mm red digits communication capability
  • Replaces
    IMS03160 IMS03162 IMS03164 IMS03166 IMS03168
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
  • Primary brand
    Red Lion
  • Sub-range name
    PAX series
  • Functions
    Strain gauge / load cell digital meter
  • Product series / family name
    Process indicators
  • Supply voltage (AC)
    85-250Vac (100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
  • Analog inputs
    1 x analog input (-24...+24mV / -240...+240mV strain gauge input DC; 16-bits conversion)
  • Order code / Manufacturer SKU
    PAXS0000
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
  • Frequency
    20Hz analog input sampling rate

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

PAXS0000 Related Documents

Red Lion - PAX ANALOG - Product Manual.pdf

Similar products from: Red Lion Industrial Automation Components

104TX on Powermatic Associates

104TX

Red Lion

Red Lion 104TX is an industrial Ethernet switch designed for automation networks. It operates with a supply voltage range of 10-30Vdc, including redundant power inputs, ensuring continuous operation. This model does not support AC supply voltage. It features 4 RJ45 ports supporting 10/100BaseTX for connectivity, with a maximum throughput of 800Mbit/s, catering to demanding industrial environments. The 104TX operates within an ambient air temperature range of -40 to +80°C, suitable for various operational climates. It boasts an IP30 degree of protection, indicating a solid metallic case designed for DIN rail mounting, which underscores its robustness for industrial settings. The communication protocol supported is Ethernet, making it compatible with a wide range of devices. This part falls under the N-Tron 100 series, indicating its place within Red Lion's lineup of industrial networking solutions.

2 in stock
PAXLBK25 on Powermatic Associates

PAXLBK25

Red Lion

Red Lion PAXLBK25 is a label kit designed for marking purposes.

15 in stock
G07C0000 on Powermatic Associates

G07C0000

Red Lion

Red Lion G07C0000 is an HMI / Display unit from the HMI Rugged Graphite series designed for indoor use. It features an HMI operator touchscreen panel with a connection type that includes 1 x RJ45 port for Ethernet, 2 x RJ11 ports for RS-232, and 1 x RJ45 port for RS-422 / RS-485 communication protocols. The supply voltage required for operation ranges from 10-30Vdc, supporting both 12Vdc and 24Vdc systems. It operates within an ambient air temperature range of -20 to +60 °C and offers a degree of protection rated at IP66 and NEMA 4X. The unit provides connection capacity for up to 5 x module slots and has a power consumption of typically 9 W, with a maximum of 37 W. The electrical durability of the backlight is rated for 50,000 hours. Additionally, it includes an SD card slot for storage and features a brightness level of 500cd/m2.

2 in stock
DA10D0C000000000 on Powermatic Associates

DA10D0C000000000

Red Lion

Red Lion DA10D0C000000000, part of the FlexEdge DA10D series, is a gateway designed for protocol conversion and data acquisition. It features a design that includes 1 x RS-232 (serial port), 1 x RS-232 / RS-485 (serial port), and 1 x Ethernet (RJ45; 10/100BaseTx) with an SD card slot for expanded functionality. The connection types available are 1 x RJ45 port (10/100BaseTX) for Ethernet connectivity, 1 x RJ12 port (RS-232 serial port), and 1 x RJ45 port (RS-232 / RS-485 serial port), supporting a range of communication protocols including RS-232, RS-485, and Ethernet. It operates on a supply voltage (DC) of 19.2-28.8Vdc, accommodating various industrial power supplies.

1 in stock
C48CS003 on Powermatic Associates

C48CS003

Red Lion

Red Lion C48CS003 is a single preset digital counter within the C48 series, designed to fit a 1/16 DIN (48x48mm) enclosure. It operates on a supply voltage range of 85-250Vac, including specific values such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac, and also supports a DC supply voltage of 11-14Vdc, specifically 12Vdc. The dimensions of this counter are standardized to 1/16 DIN, measuring W48mm x H48mm (1.89" x 1.89"). It offers a degree of protection rated at IP65 NEMA 4X, suitable for flush or door mounting. The C48CS003 features 1 high-speed digital input (12kHz; Sink/Source) labeled INPUT A, an additional digital input (Sink/Source) designated as USER INPUT 1, and a third digital input (Sink/Source) that can function as input B or USER INPUT 1. For output, it provides 1 digital output (NPN) and 1 digital output (contact type NO).

1 in stock
G10S0000 on Powermatic Associates

G10S0000

Red Lion

Red Lion G10S0000 is an HMI / Display unit from the HMI Rugged Graphite series designed for both indoor and outdoor use. It features an HMI operator touchscreen panel with a connection interface that includes 1 x RJ45 port for Ethernet, 2 x RJ11 ports for RS-232, and 1 x RJ45 port supporting both RS-422 and RS-485 communication protocols. The unit operates on a supply voltage range of 10-30Vdc, accommodating both 12Vdc and 24Vdc systems. It is engineered to function within an ambient air temperature range of -20 to +60 °C and offers a degree of protection rated at IP66 and NEMA 4X. The G10S0000 is equipped with 7 module slots for connection capacity, and its power consumption is typically 18 W, with a maximum of 53 W. The electrical durability of the backlight is rated at 35,000 hours. For storage, it includes an SD card slot, and it boasts a brightness level of 2500cd/m2.

1 in stock

Manufacturer warranty

PAXS0000 Red Lion

Get a quick Quote!

Request a quote, and we will send you price and availability within minutes.

Select Qty:

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

Compare PAXS0000 with other Industrial Automation Components products

Display

Digital inputs

Analog outputs

Degree of protection

Main function

Design

Replaces

Compliant with standard(s...

Primary brand

Sub-range name

Selected product

PAXS0000
Backordered
PAXS0000
Red Lion

Red Lion PAXS0000 is a dynamometer digital meter designed for strain gauge or load cell measurements...

Display1 row x 5-digits red charact...

Digital inputs3 x digital inputs (Sink/Sou...

Analog outputs1 x analog output (retransmi...

Degree of protectionIP65 NEMA 4X

Main functionDynamometer (Digital)

Design3 users inputs 1/8 DIN (96x4...

ReplacesIMS03160 IMS03162 IMS03164 I...

Compliant with standard(s)CE IEC 60068-2-6 (vibration)...

Primary brandRed Lion

Sub-range namePAX series

C48CS003
1 in stock
C48CS003
Red Lion

Red Lion C48CS003 is a single preset digital counter within the C48 series, designed to fit a 1/16 D...

Display2 rows x 6-digits reflective...

Digital inputs1 x digital input (high-spee...

Analog outputs-

Degree of protectionIP65 NEMA 4X

Main functionCounter (Digital)

Design1/16 DIN (48x48mm)

Replaces-

Compliant with standard(s)-

Primary brandRed Lion

Sub-range nameC48 series

G10S0000
1 in stock
G10S0000
Red Lion

Red Lion G10S0000 is an HMI / Display unit from the HMI Rugged Graphite series designed for both ind...

Display10" / 640x480pixels (VGA) to...

Digital inputs-

Analog outputs-

Degree of protectionIP66 NEMA 4X

Main functionHMI / Display unit

Designfor indoor / outdoor use

ReplacesG310S210

Compliant with standard(s)-

Primary brandRed Lion

Sub-range nameHMI Rugged Graphite series

About the manufacturer

Red Lion

Powermatic Associates is an authorized Red Lion distributor, proudly offering a wide range of their innovative industrial automation and networking products. Red Lion Controls has been a leader in delivering reliable solutions for over 50 years, specializing in advanced communication, monitoring, and control for diverse industries. Their comprehensive product line includes cutting-edge HMI operato...

Recently viewed products

Relevant products

PAXS0010 on Powermatic Associates
