64274 Schneider Electric Industrial Automation Components

64274 on Powermatic Associates
Schneider Electric

Part#:64274

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - 64274

Product Details

  • Circuit Breaker Type
    NW
  • Product Or Component Type
    Tool
  • Range Of Product
    Masterpact NW
  • Product Compatibility
    Masterpact Masterpact
  • Accessory / Separate Part Category
    Interlocking accessory

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 64274 on Powermatic Associates is $90.00. Order now.

64274 Related Documents

Instruction Sheet-1631035342795.pdfProduct Datasheet-1631035342782.pdf
