QOB330GFI5237 Schneider Electric Electronic Components

QOB330GFI5237 on Powermatic Associates
Schneider Electric

Part#:QOB330GFI5237

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

6 in stock

Sep 13, 2025

Product description

Square D by Schneider Electric QOB330GFI5237 is a Ground Fault Interrupter (GFI) Miniature Circuit Breaker (MCB) designed for bolt-on mounting. It features a rated current of 30A and a bolt-on connection type. This MCB operates at a rated voltage of 208 V AC and accommodates a wire cross-section of 14-8AWG for one copper cable. It is a 3 Pole device with a residual current sensitivity of 6mA / 0.006. The QOB330GFI5237 offers ground fault protection and has a short circuit breaking rating of 10kA at both 120Vac and 208Vac. It is equipped with ring tongue type terminals.

Product Details

  • Product
    Miniature circuit-breaker
  • Ratings
    Not rated
  • Electrical Connection
    Ring tongue
  • Interrupt Rating
    10 kA 208Y/120 V AC 50/60 Hz
  • Current Rating
    30 A
  • Width
    2.25 in (57.15 mm)
  • Mounting Type
    Bolt-on
  • Depth
    2.91 in (73.91 mm)
  • Voltage Rating
    208Y/120 V AC
  • Range
    QO
  • Number Of Poles
    3P
  • Number Of Panel Spaces
    2
  • Height
    4.12 in (104.65 mm)
  • Circuit Breaker Type
    Ground fault protecting class A 6 mA
  • Wire Size
    AWG 14...AWG 8 copper AWG 12...AWG 8 aluminium
  • Tightening Torque
    40.71 lbf.in (4.6 N.m) 0.00…0.02 in² (2.5…10 mm²) (AWG 16...AWG 14) 40.71 lbf.in (4.6 N.m) 0.01…0.03 in² (4…20 mm²) (AWG 12...AWG 4)

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

QOB330GFI5237 Related Documents

Product Datasheet-1631032625771.pdfCatalog-1631032625780.pdfInstruction Sheet-1631032625768.pdf
