9001KP1LRR31 Schneider Electric Industrial Automation Components

9001KP1LRR31 on Powermatic Associates
Schneider Electric

Part#:9001KP1LRR31

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric 9001KP1LRR31 is a pilot light designed with a plastic lens cap and features a red LED for illumination. It operates at a network frequency of 9001K with a primary voltage of 30 mm and is suitable for AC circuits at 110 V. The part is equipped with a Fresnel lens type, enhancing its visibility, and has a wavelength of 50/60 Hz. It is rated for use in environments requiring protection levels of IP66, NEMA 1, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 12, and NEMA 13, ensuring its compatibility with a wide range of industrial settings. The lens cap diameter is 1.18 inches.

Product Details

  • CAD Overall Depth
    1.65 in (42 mm)
  • CAD Overall Height
    2.76 in (70 mm)
  • Net Weight
    0.46 lb(US) (0.21 kg)
  • CAD Overall Width
    2.13 in (54 mm)
  • Short-Circuit Protection
    10 A cartridge fuse IEC 60947-5-1
  • [Uimp] Rated Impulse Withstand Voltage
    2.5 kV IEC 60947-1
  • [Ui] Rated Insulation Voltage
    250 V 2)IEC 60947-1
  • Tightening Torque
    7.08 lbf.in (0.8 N.m) IEC 60947-1
  • Shape Of Screw Head
    Cross slotted
  • Operating Position
    Any position
  • Connections - Terminals
    Screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
  • Bulb Base
    BA 9s
  • Light Source
    Red LED
  • [Ith] Conventional Free Air Thermal Current
    10 A
  • Light Block Supply
    Direct 110...120 V AC 50/60 Hz
  • Cap/Operator Or Lens Colour
    Red
  • Lens Type
    Domed plastic
  • Shape Of Signaling Unit Head
    Round
  • Mounting Diameter
    1.18 in (30 mm)
  • Range Of Product
    Harmony 9001K
  • Bezel Material
    Chromium plated metal
  • Product Or Component Type
    Pilot light
  • Device Short Name
    9001K

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 9001KP1LRR31 on Powermatic Associates is $153.00. Order now.

9001KP1LRR31 Related Documents

Instruction Sheet-1631036960940.pdfProduct Datasheet-1631036960927.pdf
