DF141V Schneider Electric Industrial Automation Components

Product Details

• Control Type
  Toggle
• Mounting Support
  35 mm symmetrical DIN rail
• Depth
  3.01 in (76.5 mm)
• [Ie] Rated Operational Current
  50 A
• Tightening Torque
  30.98 lbf.in (3.5 N.m)
• Product Name
  TeSys DF
• Poles Description
  1P
• [Ipk] Rated Peak Withstand Current
  15 kA with tubular links IEC 60269-1
• Device Short Name
  DF14
• Height
  4.36 in (110.8 mm)
• Range
  TeSys
• Local Signalling
  Blown fuse indication
• [Uimp] Rated Impulse Withstand Voltage
  8 kV
• Product Or Component Type
  Fuse carrier
• Quantity Per Set
  Set of 6
• Width
  1.04 in (26.5 mm)
• Mounting Position
  Vertical +/- 23°)
• Fuse Size
  14 x 51 mm
• Net Weight
  0.32 lb(US) (0.143 kg)
• [Ui] Rated Insulation Voltage
  690 V AC
Product Compatibility
DF2EA fuse cartridge DF2EN fuse cartridge
[Ue] Rated Operational Voltage
690 V AC 690 V DC
Fuse Type
, aM , gG
Short-Circuit Withstand
120 kA 400 V IEC 60947-3 120 kA 500 V IEC 60947-3 80 kA 690 V IEC 60947-3
Connections - Terminals
screw clamp terminals 1 0.00…0.04 in² (2.5…25 mm²)rigid screw clamp terminals 2 0.00…0.02 in² (2.5…10 mm²)rigid screw clamp terminals 1 0.00…0.04 in² (2.5…25 mm²)flexible with or without screw clamp terminals 2 0.00…0.02 in² (2.5…10 mm²)
Standards
EN/IEC 60947-3 EN/IEC 60269-2 UL 4248-1 CSA C22.2 No 4248-1
Product Certifications
IEC UL Recognized CSA EAC
