Part#:DF101

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

10 in stock

Jul 1, 2025

Product description

Schneider Electric - DF101

Product Details

  • Height
    3.13 in (79.5 mm)
  • Fuse Type
    , aM , gG
  • [Ith] Conventional Free Air Thermal Current
    32 A 68 °F (20 °C)
  • Net Weight
    0.09 lb(US) (0.042 kg)
  • Poles Description
    1P
  • Power Dissipation In W
    3 W maximum power dissipation by fuse
  • Product Name
    TeSys DF
  • Control Type
    Toggle padlockable
  • Overvoltage Category
    III
  • Width
    0.69 in (17.5 mm)
  • Range
    TeSys
  • [Ui] Rated Insulation Voltage
    690 V AC
  • Mounting Position
    Vertical +/- 23°)
  • Device Short Name
    DF10
  • Fuse Size
    10 x 38 mm
  • Depth
    2.40 in (61 mm)
  • Product Or Component Type
    Fuse carrier
  • [Uimp] Rated Impulse Withstand Voltage
    6 kV
  • Quantity Per Set
    Set of 12
  • [Ie] Rated Operational Current
    32 A 400 V AC
  • Mounting Support
    35 mm symmetrical DIN rail
  • Tightening Torque
    19.47 lbf.in (2.2 N.m) PZ2 19.47 lbf.in (2.2 N.m) flat Ø 5.5 mm
  • [Ue] Rated Operational Voltage
    690 V AC 690 V DC
  • Utilisation Category
    AC-20B IEC 60947-3 DC-20B IEC 60947-3
  • Short-Circuit Withstand
    120 kA 400 V IEC 60947-3 120 kA 500 V IEC 60947-3
  • Product Compatibility
    DF2CA fuse cartridge DF2CN fuse cartridge
  • Connections - Terminals
    screw clamp terminals 1 0.00…0.02 in² (1…16 mm²)rigid screw clamp terminals 2 0.00…0.01 in² (1…6 mm²)rigid screw clamp terminals 1 0.00…0.02 in² (1…16 mm²)flexible with or without screw clamp terminals 2 0.00…0.01 in² (1…6 mm²)flexible w
  • Product Certifications
    IEC UL Recognized CSA CCC EAC DNV-GL
  • Standards
    EN/IEC 60947-3 EN/IEC 60269-2 UL 4248-1 CSA C22.2 No 4248-1 EN 45545-2: R22 HL2

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
