EGB24035SA Schneider Electric Industrial Automation Components

EGB24035SA on Powermatic Associates
Schneider Electric

Part#:EGB24035SA

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - EGB24035SA

Product Details

  • Device Short Name
    EGB
  • Number Of Spaces Required
    3
  • Trip Unit Rating
    1800 A
  • Number Of Poles
    2
  • Module Type
    E-Frame
  • Net Weight
    3 lb(US) (1.36 kg)
  • Holding Current
    630 A
  • Width
    2.94 in (74.68 mm)
  • Maximum Operating Voltage
    480Y/277 V AC
  • Local Signalling
    Trip indicator
  • Height
    5.66 in (143.76 mm)
  • Range Of Product
    125 A Frame EDB-EGB-EJB
  • Number Of Spaces
    3
  • Line Rated Current
    35 A
  • Electrical Connection
    Lugs aluminium
  • Breaking Capacity Code
    G
  • Product Or Component Type
    Miniature circuit-breaker
  • Mounting Mode
    Bolt-on
  • Device Composition
    Shunt trip
  • Depth
    4.05 in (102.87 mm)
  • Product Destination
    NF panelboard
  • Trip Unit Technology
    Thermal-magnetic
  • AWG Gauge
    AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
  • Protection Type
    Short-circuit Overload
  • Tightening Torque
    34.52 lbf.in (3.9 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 49.56 lbf.in (5.6 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)
  • Circuit Breaker Application
    HID rated HACR rated
  • Breaking Capacity
    35 kA 277 V AC 65 kA 240 V AC 35 kA 480Y/277 V AC 65 kA 120 V AC 65 kA 120/240 V AC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EGB24035SA on Powermatic Associates is $1,531.00. Order now.
