EJB34050CA Schneider Electric Industrial Automation Components

Product Details

• Maximum Operating Voltage
  480Y/277 V AC
• Product Or Component Type
  Miniature circuit-breaker
• Number Of Spaces
  3
• Depth
  4.05 in (102.87 mm)
• Line Rated Current
  50 A
• Net Weight
  4 lb(US) (1.81 kg)
• Device Short Name
  EJB
• Number Of Poles
  3
• Holding Current
  630 A
• Breaking Capacity Code
  J
• Trip Unit Rating
  1800 A
• Local Signalling
  Trip indicator
• Width
  2.94 in (74.68 mm)
• Number Of Spaces Required
  3
• Range Of Product
  125 A Frame EDB-EGB-EJB
• Mounting Mode
  Bolt-on
• Height
  5.66 in (143.76 mm)
• Module Type
  E-Frame
• Product Destination
  NF panelboard
• Electrical Connection
  Lugs aluminium
Trip Unit Technology
Thermal-magnetic
AWG Gauge
AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
Circuit Breaker Application
HACR rated HID rated
Protection Type
Overload Short-circuit
Tightening Torque
34.52 lbf.in (3.9 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 49.56 lbf.in (5.6 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)
Breaking Capacity
65 kA 277 V AC 100 kA 240 V AC 65 kA 480Y/277 V AC 100 kA 120 V AC 100 kA 120/240 V AC
