Part#:EJB34090

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric EJB34090 is a Miniature Circuit Breaker (MCB) designed for bolt-on mounting with a visual trip indicator. It features lugs terminals and operates at a rated voltage of 480 V AC. This MCB is equipped with short-circuit and overload protection functions, serving as both an Equipment Protection Device (EPD) and a Circuit Breaker (CB) with a breaking capacity code J. It offers an aluminium lugs connection and supports a rated current of 90A across 3 poles. The cross-section compatibility ranges from 12 to 2/0 AWG. Its short circuit breaking rating is specified at 100kA for 120Vac and 240Vac, and 65kA for 480Y/277Vac. The EJB34090 utilizes a thermal-magnetic trip unit with protection settings at a trip unit rating of 2300A.

Product Details

  • Breaking Capacity
    65 kA 277 V AC 100 kA 240 V AC 65 kA 480Y/277 V AC 100 kA 120 V AC 100 kA 120/240 V AC
  • Tightening Torque
    34.52 lbf.in (3.9 N.m) 0.00…0.01 in² (2.5…6 mm²) (AWG 14...AWG 10) 49.56 lbf.in (5.6 N.m) 0.02…0.11 in² (10…70 mm²) (AWG 8...AWG 2/0)
  • Protection Type
    Short-circuit Overload
  • AWG Gauge
    AWG 12...AWG 2/0 aluminium AWG 14...AWG 2/0 copper
  • Width
    2.94 in (74.68 mm)
  • Net Weight
    4 lb(US) (1.81 kg)
  • Depth
    4.05 in (102.87 mm)
  • Height
    5.66 in (143.76 mm)
  • Breaking Capacity Code
    J
  • Trip Unit Technology
    Thermal-magnetic
  • Number Of Poles
    3
  • Local Signalling
    Trip indicator
  • Holding Current
    1000 A
  • Number Of Spaces Required
    3
  • Product Destination
    NF panelboard
  • Number Of Spaces
    3
  • Mounting Mode
    Bolt-on
  • Electrical Connection
    Lugs aluminium
  • Circuit Breaker Application
    HACR rated
  • Module Type
    E-Frame
  • Trip Unit Rating
    2300 A
  • Maximum Operating Voltage
    480Y/277 V AC
  • Line Rated Current
    90 A
  • Device Short Name
    EJB
  • Product Or Component Type
    Miniature circuit-breaker
  • Range Of Product
    125 A Frame EDB-EGB-EJB

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of EJB34090 on Powermatic Associates is $2,562.00. Order now.

EJB34090 Related Documents

Instruction Sheet-1631035061711.pdfProduct Datasheet-1631035061696.pdfCatalog-1631035061705.pdf

Similar products from: Schneider Electric Industrial Automation Components

LC1D95M7 on Powermatic Associates

LC1D95M7

Schneider Electric

Schneider Electric LC1D95M7 is a magnetic contactor from the Deca sub-range, featuring screw connections and three poles (3P; 3NO). It has a rated current of 125A (AC-1) and 95A (440Vac; AC-3), with a mounting mode designed for DIN rail installation. The net width of the contactor is 85 mm, and it offers a degree of protection rated at IP20. The control voltage (AC) ranges from 176-242Vac (220Vac nom.; 50Hz; 0.8...1.1 x Uc) to 187-242Vac (220Vac nom.; 60Hz; 0.85...1.1 x Uc), with a rated operating voltage (Ue) of 1000 V. It includes 1 normally open (NO) auxiliary contact and 1 normally closed (NC) auxiliary contact, both of the instantaneous type (1NO+1NC). The rated impulse voltage (Uimp) is 8 kV. This contactor is capable of handling rated active power ranging from 25kW (220-230Vac; AC-3) to 55kW (500Vac; AC-3), with specific ratings for various voltages up to 1000Vac. It also supports rated power (HP) for motors from 7.5HP (115Vac; single-phase) to 60HP (575-600Vac; 3-phase), under UL/CSA standards. The mechanical durability of the LC1D95M7 is rated at 4,000,000 operations, and its electrical durability (with load) is rated at 1,200,000 operations. The rated voltage (AC) for phase-to-phase connections is 1000 V.

17 in stock
MGN61508 on Powermatic Associates

MGN61508

Schneider Electric

Schneider Electric MGN61508 is a Miniature Circuit Breaker (MCB) designed for DC applications. It falls under the C60H-DC sub-range and features a rated current of 10A with a rated voltage of 250V DC. This MCB is equipped with 1 pole that is protected and utilizes a C tripping curve.

32 in stock
NSYTRACRE24 on Powermatic Associates

NSYTRACRE24

Schneider Electric

Schneider Electric - NSYTRACRE24

30 in stock
M9F43303 on Powermatic Associates

M9F43303

Schneider Electric

Schneider Electric M9F43303 is a Miniature Circuit Breaker (MCB) within the C60BP sub-range, designed with a 3-pole configuration. It has a rated current of 3A and features a rated insulation voltage (Ui) of 500V. This MCB operates with a rated voltage of 60Vdc and has a rated impulse voltage (Uimp) of 6kV. It offers a short circuit breaking rating of 14kA AIR at both 120Vac and 240Vac, and 10kA AIR at 480Y/277Vac and 60Vdc. The rated voltage for AC applications is 240V phase-to-neutral and 415V phase-to-phase. All three poles are protected, and it is equipped with a D tripping curve.

5 in stock
VW3A9921 on Powermatic Associates

VW3A9921

Schneider Electric

Schneider Electric VW3A9921 is an adapter designed for direct circuit breaker mounting. This mechanical adapter kit facilitates the integration of components by providing a compatible interface for secure and straightforward installation.

12 in stock
M9F53220 on Powermatic Associates

M9F53220

Schneider Electric

Schneider Electric M9F53220 is a Miniature Circuit Breaker (MCB) within the C60BPR sub-range, designed with a 2 Pole configuration and a rated current of 20A. It features a rated insulation voltage (Ui) of 500 V and a rated impulse voltage (Uimp) of 6 kV. The M9F53220 offers a short circuit breaking rating of 14kA AIR at both 120Vac and 240Vac, and 10kA AIR at 480Y/277Vac and 125Vdc. It supports a rated voltage (AC) for phase-to-phase connections up to 440 V and has 2 protected poles. The tripping curve for this MCB is classified as D.

1 in stock

Manufacturer warranty

EJB34090 Schneider Electric

$2,562.00

Your price can be lower.
Log in or Create account to check your discount

Select Qty:

$2,562.00

$2,562.00 each

Average response time: 11 minutes

Worldwide Shipping and Delivery

Secure Payment Processing

Warranty

Responsive Customer Support

Got Questions? We've Got Answers!

Need more details?

Feel free to chat with us

Compare EJB34090 with other Industrial Automation Components products

Breaking Capacity

Tightening Torque

Protection Type

AWG Gauge

Width

Net Weight

Depth

Height

Breaking Capacity Code

Trip Unit Technology

Selected product

EJB34090
Backordered
EJB34090
Schneider Electric

Square D by Schneider Electric EJB34090 is a Miniature Circuit Breaker (MCB) designed for bolt-on mo...

Breaking Capacity65 kA 277 V AC 100 kA 240 V ...

Tightening Torque34.52 lbf.in (3.9 N.m) 0.00…...

Protection TypeShort-circuit Overload

AWG GaugeAWG 12...AWG 2/0 aluminium A...

Width2.94 in (74.68 mm)

Net Weight4 lb(US) (1.81 kg)

Depth4.05 in (102.87 mm)

Height5.66 in (143.76 mm)

Breaking Capacity CodeJ

Trip Unit TechnologyThermal-magnetic

EDB34040
34 in stock
EDB34040
Schneider Electric

Square D by Schneider Electric EDB34040 is a Miniature Circuit Breaker (MCB) designed for bolt-on mo...

Breaking Capacity18 kA 277 V AC 25 kA 240 V A...

Tightening Torque-

Protection Type-

AWG GaugeAWG 12...AWG 2/0 aluminium A...

Width-

Net Weight-

Depth-

Height-

Breaking Capacity Code-

Trip Unit Technology-

QOU3155283
