Part#:EX112T212H

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Low Voltage Transformer, DOE 2016, 3 Phase, 112.5 kVA, 208V Delta primary / 480Y/277V secondary, AL, 150°C Rise

Product Details

  • Coil Material
    Aluminium
  • Transformer Type
    Energy efficient
  • X/R Ratio
    1.45
  • Product Or Component Type
    Transformer
  • Height
    45.98 in (1168 mm)
  • Phase
    3 phase
  • %IZ
    4.60 %
  • Depth
    24.02 in (610 mm)
  • Primary Voltage
    208 V delta
  • Rated Operational Power In VA
    112.5 kVA
  • Let Through Current
    2.9 kA
  • Net Weight
    865.01 lb(US) (392.36 kg)
  • Basic IMP Level (BIL)
    10 kV
  • Network Frequency
    60 Hz
  • Secondary Voltage
    480Y/277 V
  • Range Of Product
    Square D
  • Type Of Cooling
    Natural convection
  • Device Application
    Low voltage electrical distribution
  • %IX
    0.0379 %
  • Device Short Name
    DOE 2016
  • DOE Efficiency
    98.83 % at 35 % load factor , 167 °F (75.0 °C)
  • Width
    31.30 in (795 mm)
  • Temperature Rise
    150 °C 220 °C insulated
  • Number Of Tap-Offs
    1 5 % FCAN 2 5 % FCBN
  • Transformer Losses
    175.0 no load (core loss) 2928.0 load loss (coil loss)
  • Sound Level
    47 dB 6 dB NEMA ST-20
  • Mounting Support
    Floor Floor, with 7400FMB Ceiling, with 7400CMB21K
  • Electrical Connection
    4 Hole Nema Pad primary 0.44 in (11.1 mm) 4 Hole Nema Pad secondary 0.44 in (11.1 mm) 6 Hole Nema Pad sec - HO 0.44 in (11.1 mm)
  • Degree Of Protection
    UL type 1 UL type 2, with 7400DS21K UL type 3R, with 7400WS21K
  • Transformer BTU/HR
    872.4300059394559 16.6 % 1221.546836 25 % 3094.812794 50 % 6216.922724 75 % 10587.876626 100 %

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
