FA26050AB Schneider Electric Industrial Automation Components

FA26050AB on Powermatic Associates
Schneider Electric

Part#:FA26050AB

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric FA26050AB is a Moulded Case Circuit Breaker (MCCB) designed for mounting on a mounting plate. It operates at a rated voltage of 600 V AC and 250 V DC, with a rated current of 50A. This MCCB features thermal protection for overload scenarios and magnetic protection for short-circuit conditions. It is specifically designed for AB phases connection and utilizes an I-Line connection on the line side and lugs on the load side. The FA26050AB has 2 poles, with both poles protected, and offers a short circuit breaking rating of 25kA at 240Vac, 18kA at both 480Y/277Vac and 480Vac, and 14kA at both 600Y/347Vac and 600Vac. The trip current rating is set at 50 AT, with a frame current rating of 100 AF. Its trip unit type is thermal-magnetic (fixed).

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
