HJL36030C Schneider Electric Industrial Automation Components

HJL36030C on Powermatic Associates
Schneider Electric

Part#:HJL36030C

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HJL36030C is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HJL sub-range, featuring a PowerPact H-Frame 150 TMD design. This 3-pole (3P) circuit breaker is rated for 30A with a rated insulation voltage (Ui) of 750 V, and it operates at a rated voltage (AC) of 600Vac 600Y/347Vac and a rated voltage (DC) of 250Vdc. It offers thermal protection for overload scenarios and magnetic protection for short-circuits, with a rated operating voltage (Ue) of 690 V and a rated impulse voltage (Uimp) of 8 kV. The device is designed for individual unit mount on plate, featuring lugs on both load and line sides for connection, and it operates via a toggle (manual) mechanism. Its protection settings include over-current fixed at 30A, short-circuit hold current fixed at 350A, and short-circuit trip current fixed at 750A. The HJL36030C has a net height of 163 mm, a net width of 104 mm, and a net depth of 86 mm, with a degree of protection of IP40. Its trip unit type is thermal-magnetic (fixed) without a display, and it has a frame current rating of 150 AF with a trip current rating of 30 AT. The short circuit breaking rating varies by voltage, with 100kA at 240Vac, 65kA at 480Vac and 480Y/277Vac, 25kA at 600Vac and 600Y/347Vac, and 20kA at 250Vdc, all according to UL489 standards. It falls under utilisation category A.

Product Details

  • Line Rated Current
    30 A
  • Depth
    4.36 in (110.74 mm)
  • Mounting Mode
    Unit mount
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Product Or Component Type
    Circuit breaker
  • Number Of Poles
    3P
  • Magnetic Hold Current
    350 A
  • Range Of Product
    PowerPact H
  • Continuous Current Rating
    100 %
  • Width
    4.12 in (104.65 mm)
  • Height
    6.4 in (162.56 mm)
  • Magnetic Tripping Current
    750 A
  • Breaking Capacity Code
    J
  • Electrical Connection
    Lugs load Lugs line

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
