Part#:HJL36060U43X

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HJL36060U43X is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HJL sub-range, featuring a PowerPact H-Frame 150 Micrologic 5.2A (LSI) design. It is a 3-pole (3P) device with a rated current of 60A and offers a variety of protection functions including Long-time (L), Short-time with fixed time delay (S), Instantaneous (I), and Zone Selective Interlocking (ZSI). The breaker has a rated insulation voltage (Ui) of 750 V, with AC rated voltages of 600Vac and 600Y/347Vac, and a DC rated voltage of 250Vdc. It is designed for individual unit mount on plate, with dimensions of 163 mm in height, 104 mm in width, and 86 mm in depth. The degree of protection is IP40, and it operates with a toggle (manual) mechanism. Protection settings are adjustable, with L protection ranging from 0.25 to 1 x In (15A to 60A), S protection from 1.5 to 10 x Ir (90A to 600A), and I protection from 1.5 to 15 x In (90A to 900A). The rated operating voltage (Ue) is 690 V, and the rated impulse voltage (Uimp) is 8 kV. The trip current rating is 60 AT, with a frame current rating of 150 AF. Its short circuit breaking rating varies with voltage, up to 100kA at 240Vac according to UL489 standards. The trip unit features an electronic Micrologic Ammeter 5.2A with LSI protection and an LCD display. Measurement functions include current measurements for phases and neutral, RMS instantaneous current, current unbalance, highest RMS current of the three phases, ground fault current, and demand/peak current values with an adjustable calculation window of 5-60min. The utilisation category is A.

Product Details

  • Electrical Connection
    Lugs load Lugs line
  • Depth
    4.36 in (110.74 mm)
  • Continuous Current Rating
    80 %
  • Width
    4.12 in (104.65 mm)
  • Height
    6.4 in (162.56 mm)
  • Line Rated Current
    60 A
  • Mounting Mode
    Unit mount
  • Breaking Capacity Code
    J
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Product Or Component Type
    Circuit breaker
  • Number Of Poles
    3P
  • Range Of Product
    PowerPact H

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HJL36060U43X on Powermatic Associates is $4,338.00. Order now.
