HLL26100 Schneider Electric Industrial Automation Components

HLL26100 on Powermatic Associates
Schneider Electric

Part#:HLL26100

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HLL26100 is a Moulded Case Circuit Breaker (MCCB) from the PowerPacT HLL sub-range, designed with a PowerPact H-Frame 150 TMD 2P 100A 600Vac/500Vdc 50kA with lugs 80% rated. It features lugs on both load and line sides for connections and operates with 2 poles (2P). This MCCB offers thermal protection for overload scenarios and magnetic protection for short-circuits, with a rated current of 100A. The rated insulation voltage (Ui) is 750 V, with an AC rated voltage of 600Vac 600Y/347Vac and a DC rated voltage of 500Vdc. It is designed for individual unit mount on plate, with a net height of 163 mm, width of 104 mm, and depth of 86 mm. The degree of protection is IP40, and it operates with a toggle (manual) mode. Protection settings include over-current fixed at 100A, short-circuit hold current fixed at 900A, and short-circuit trip current fixed at 1700A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 100 AT, with a frame current rating of 150 AF. It has a short circuit breaking rating of 125kA (240Vac; UL489), 100kA (480Vac; UL489), 100kA (480Y/277Vac; UL489), 50kA (600Vac; UL489), 50kA (600Y/347Vac; UL489), 20kA (250Vdc; UL489), and 50kA (500Vdc; UL489). The trip unit type is thermal-magnetic (fixed) with no display, and it falls under utilisation category A.

Product Details

  • Electrical Connection
    Lugs load Lugs line
  • Continuous Current Rating
    80 %
  • Depth
    4.36 in (110.74 mm)
  • Width
    4.12 in (104.65 mm)
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Height
    6.4 in (162.56 mm)
  • Breaking Capacity Code
    L
  • Magnetic Tripping Current
    1700 A
  • Magnetic Hold Current
    900 A
  • Mounting Mode
    Unit mount
  • Number Of Poles
    2P
  • Line Rated Current
    100 A
  • Product Or Component Type
    Circuit breaker
  • Range Of Product
    PowerPact H

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HLL26100 on Powermatic Associates is $3,919.50. Order now.
