Part#:HLL36030C

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric HLL36030C is a Moulded Case Circuit Breaker (MCCB) within the PowerPacT HLL sub-range, featuring a PowerPact H-Frame 150 TMD design. It is a 3-pole (3P) device with a rated current of 30A and offers thermal protection for overload and magnetic protection for short-circuit scenarios. The breaker is designed for a rated insulation voltage (Ui) of 750 V, with AC rated voltages of 600Vac and 600Y/347Vac, and a DC rated voltage of 500Vdc. It supports a mounting mode of individual unit mount on plate, has a net height of 163 mm, a width of 104 mm, and a depth of 86 mm. The degree of protection is IP40, and it operates via a toggle (manual) mechanism. Protection settings include over-current fixed at 30A, short-circuit hold current fixed at 350A, and short-circuit trip current fixed at 750A. The rated operating voltage (Ue) is 690 V, with a rated impulse voltage (Uimp) of 8 kV. The trip current rating is 30 AT, with a frame current rating of 150 AF. Its short circuit breaking rating varies across voltages, with 125kA at 240Vac, 100kA at 480Vac and 480Y/277Vac, 50kA at 600Vac and 600Y/347Vac, 20kA at 250Vdc, and 50kA at 500Vdc, all under UL489. The trip unit type is thermal-magnetic (fixed), and it does not include a display. The utilisation category is A, and it features lugs on both load and line sides for connections.

Product Details

  • Electrical Connection
    Lugs load Lugs line
  • Continuous Current Rating
    100 %
  • Depth
    4.36 in (110.74 mm)
  • Width
    4.12 in (104.65 mm)
  • Height
    6.4 in (162.56 mm)
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.00…0.15 in² (2.5…95 mm²) (AWG 14...AWG 3/0)
  • Magnetic Hold Current
    350 A
  • Magnetic Tripping Current
    750 A
  • Number Of Poles
    3P
  • Mounting Mode
    Unit mount
  • Breaking Capacity Code
    L
  • Line Rated Current
    30 A
  • Product Or Component Type
    Circuit breaker
  • Range Of Product
    PowerPact H

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of HLL36030C on Powermatic Associates is $3,419.00. Order now.
