JJM36250 Schneider Electric Industrial Automation Components

JJM36250 on Powermatic Associates
Schneider Electric

Part#:JJM36250

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric - JJM36250

Product Details

  • Shipping Height:
    4.00 In.
  • Shipping Weight:
    4.25 lbs.
  • UPC:
    78590106832
  • Shipping Length:
    8.00 In.
  • Shipping Width:
    4.00 In.
  • TS PIK:
    120071825
  • Electrical Connection
    Lugs line Terminal nut load
  • Continuous Current Rating
    80 %
  • Depth
    5 in (127.00 mm)
  • Width
    4.12 in (104.65 mm)
  • Height
    7.52 in (191.01 mm)
  • Magnetic Tripping Current
    2500 A
  • Tightening Torque
    230.12 lbf.in (26 N.m) 0.15…0.29 in² (95…185 mm²) (AWG 3/0...350 kcmil)
  • Breaking Capacity Code
    J
  • Product Or Component Type
    Circuit breaker
  • Magnetic Hold Current
    1250 A
  • Number Of Poles
    3P

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of JJM36250 on Powermatic Associates is $7,238.00. Order now.
