Part#:M9F12250

Manufacturer:Schneider Electric

Category:Electronic Components

Product Lifecycle:Active

Product description

Multi9 - C60N - MCB - 2P - 50 A - D Curve - 415 V - 10 kA

Product Details

  • Suitability For Isolation
    Yes conforming to EN/IEC 60947-2
  • Local Signalling
    ON/OFF indication
  • Provision For Padlocking
    Padlockable
  • Number Of Protected Poles
    2
  • Device Application
    Distribution
  • Control Type
    Toggle
  • Depth
    2.83 in (72 mm)
  • Product Name
    Multi 9 C60
  • Curve Code
    D
  • [Ui] Rated Insulation Voltage
    500 V AC 50/60 Hz EN/IEC 60947-2
  • Electrical Durability
    10000 cycles
  • Wire Stripping Length
    0.55 in (14 mm) top or bottom
  • Line Rated Current
    50 A 122 °F (50 °C) EN/IEC 60947-2
  • Contact Position Indicator
    Yes
  • Mechanical Durability
    20000 cycles
  • Poles Description
    2P
  • Trip Unit Technology
    Thermal-magnetic
  • Mounting Support
    DIN rail
  • Range
    Multi 9
  • Utilisation Category
    Category A EN/IEC 60947-2
  • 9 Mm Pitches
    4
  • Tightening Torque
    30.98 lbf.in (3.5 N.m) top or bottom
  • Product Or Component Type
    Miniature circuit-breaker
  • Standards
    EN/IEC 60947-2
  • [Uimp] Rated Impulse Withstand Voltage
    6 kVEN/IEC 60947-2
  • Height
    3.19 in (81 mm)
  • Device Short Name
    C60N
  • Network Frequency
    50/60 Hz
  • Mounting Mode
    Clip-on
  • Net Weight
    0.53 lb(US) (0.24 kg)
  • Width
    1.42 in (36 mm)
  • Color
    Gray
  • Earth-Leakage Protection
    Separate block
  • Product Certifications
    EAC KC
  • Magnetic Tripping Limit
    12 x In +/- 20 % AC 17 x In +/- 20 % DC
  • Network Type
    DC AC
  • Connections - Terminals
    Tunnel type terminal top or bottom) 0.00…0.05 in² (1.5…35 mm²) - rigid Tunnel type terminal top or bottom) 0.00…0.05 in² (1.5…35 mm²) - flexible Tunnel type terminal top or bottom) 0.00…0.05 in² (1.5…35 mm²) - flexible with ferrule
  • [Ue] Rated Operational Voltage
    240 V AC 50/60 Hz between phases 415 V AC 50/60 Hz between phases 440 V AC 50/60 Hz between phases <= 125 V DC
  • Breaking Capacity
    20 kA Icu <= 125 V DC EN/IEC 60947-2 10 kA Icu 415 V AC 50/60 Hz between phases EN/IEC 60947-2 20 kA Icu 240 V AC 50/60 Hz between phases EN/IEC 60947-2 6 kA Icu 440 V AC 50/60 Hz between phases EN/IEC 60947-2
  • [Ics] Rated Service Breaking Capacity
    7.5 kA 75 % EN/IEC 60947-2 - 415 V AC 50/60 Hz 16 kA 75 % EN/IEC 60947-2 - 240 V AC 50/60 Hz 4.5 kA 75 % EN/IEC 60947-2 - 440 V AC 50/60 Hz 20 kA 100 % EN/IEC 60947-2 - <= 125 V DC

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

M9F12250 Related Documents

Product Datasheet-1631032166233.pdf

Similar products from: Schneider Electric Electronic Components
