M9U11210 Schneider Electric Industrial Automation Components

M9U11210 on Powermatic Associates
Schneider Electric

Part#:M9U11210

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Schneider Electric M9U11210 is a Miniature Circuit Breaker (MCB) designed specifically for DC loads, falling under the C60H-DC sub-range. This MCB features a 2-pole configuration, with both poles protected, and is rated for a current of 10A at a voltage of up to 500Vdc. It has a short circuit breaking rating of 5kA AIR at 500Vdc. The tripping curve for this device is classified as type B, ensuring compliance with UL1077 standards for safety and performance in electrical circuit protection.

Product Details

  • Number Of Protected Poles
    2
  • Mounting Mode
    Clip-on
  • Mechanical Durability
    20000 cycles
  • Device Application
    Distribution
  • Control Type
    Toggle
  • Poles Description
    2P
  • Mounting Support
    DIN rail
  • Device Short Name
    C60H-DC
  • Curve Code
    B
  • Local Signalling
    ON/OFF indication
  • Width
    1.42 in (36 mm)
  • Product Name
    Multi 9 C60H-DC
  • Utilisation Category
    Category A EN/IEC 60947-2
  • [Uimp] Rated Impulse Withstand Voltage
    6 kVEN/IEC 60947-2
  • Depth
    2.87 in (73 mm)
  • Range
    Multi 9
  • Trip Unit Technology
    Thermal-magnetic
  • Magnetic Tripping Limit
    3…7 x In DC
  • Height
    3.19 in (81 mm)
  • Provision For Padlocking
    Padlockable
  • Product Or Component Type
    Miniature circuit-breaker
  • Suitability For Isolation
    Yes EN/IEC 60947-2
  • [Ui] Rated Insulation Voltage
    500 V DC EN/IEC 60947-2
  • Line Rated Current
    10 A 77 °F (25 °C) EN/IEC 60947-2
  • Tightening Torque
    22.13 lbf.in (2.5 N.m) top or bottom
  • Contact Position Indicator
    Yes
  • Net Weight
    0.28 lb(US) (0.128 kg)
  • Wire Stripping Length
    0.55 in (14 mm) top or bottom
  • Color
    Gray
  • Network Type
    DC
  • 9 Mm Pitches
    4
  • Earth-Leakage Protection
    Without
  • Electrical Durability
    3000 cycles 250 V DC L/R = 2 ms 6000 cycles 250 V DC
  • Connections - Terminals
    Tunnel type terminal top or bottom) 0.00…0.04 in² (1…25 mm²) AWG 18...AWG 4) - rigid stranded Tunnel type terminal top or bottom) 0.00…0.02 in² (1…16 mm²) AWG 18...AWG 6) - flexible Tunnel type terminal top or bottom) 0.00…0.02 in² (1…16 mm²) AW
  • [Ue] Rated Operational Voltage
    220 V DC 440 V DC 500 V DC
  • Standards
    EN/IEC 60947-2 GB 14048.2 UL 1077
  • Product Certifications
    IEC CCC UR
  • [Ics] Rated Service Breaking Capacity
    7.5 kA 75 % EN/IEC 60947-2 - 440 V DC 4.5 kA 75 % EN/IEC 60947-2 - 500 V DC 15 kA 75 % EN/IEC 60947-2 - 220 V DC 7.5 kA 75 % GB 14048.2 - 440 V DC 4.5 kA 75 % GB 14048.2 - 500 V DC 15 kA 75 % GB 14048.2 - 220 V DC
  • Breaking Capacity
    20 kA Icu 220 V DC EN/IEC 60947-2 10 kA Icu 440 V DC EN/IEC 60947-2 6 kA Icu 500 V DC EN/IEC 60947-2 5 kA AIR 12...500 V DC UL 1077 20 kA Icu 220 V DC GB 14048.2 10 kA Icu 440 V DC GB 14048.2 6 kA Icu 500 V DC GB 14048.2

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of M9U11210 on Powermatic Associates is $392.00. Order now.
