NSYTRV162SF Schneider Electric Industrial Automation Components

Product Details

• Product Or Component Type
  Terminal block
• Connection Position
  Sideways
• Terminal Block Level
  1
• Device Short Name
  TRV
• Quantity Per Set
  Set of 50
• Device Application
  Protection
• Fuse Size
  5 x 20 mm
• Tightening Torque
  13.28…15.93 lbf.in (1.5…1.8 N.m)
• Product Name
  TR
• Color
  Black
• Terminal Block Type
  Fixed carrier
• Length
  2.44 in (62 mm)
• Net Weight
  1.19 oz (33.8 g)
• Number Of Measurement Input
  0
• Flame Retardance
  V0 0.03 in (0.8 mm) UL 94
• Mounting Mode
  Clip-on
• Associated Connection Component
  Cylindrical fuse
• Number Of Connections
  2
• Wire Stripping Length
  0.43 in (11 mm)
• Width
  0.47 in (12 mm)
Height
2.25 in (57.2 mm)
Range
Linergy
Nominal Cross Section
0.02 in² (16 mm²)
Material
Polyamide 6/6 insulating case
Dielectric Constant
3.7 at 1 MHz
Product Compatibility
Spacial enclosures
Surface Resistance
1000 MOhm IEC 60093 1000 MOhm VDE 0303-T30
Tool Type
Connection screwdriver Disconnection screwdriver
Connections - Terminals
1 x screw terminal upstream 1 x screw terminal downstream
Creep Resistance
500 CTI (> 400 kB) IEC 60093 500 CTI (> 400 kB) VDE 0303-T30
Dielectric Loss
0.01 at 1 MHz IEC 60250 0.01 at 1 MHz VDE 0303-T4
Resistivity
10000 Ω.cm IEC 60093 10000 Ω.cm VDE 0303-T30
Line Rated Current
10 A EN/IEC 60947-7-1 20 A cURus 20 A CSA
[Ue] Rated Operational Voltage
500 V EN/IEC 60947-7-1 300 V cURus 300 V CSA
Cable Cross Section
0.00…0.02 in² (1.5…16 mm²), flexible with cable end 0.00…0.00 in² (0.08…2.5 mm²), flexible without cable end 0.00…0.02 in² (0.5…16 mm²), solid without cable end
Range Compatibility
Prisma G Prisma P Prisma PH Prisma Pack Spacial Kaedra Pragma TeSys
