QOU160VH Schneider Electric Industrial Automation Components

QOU160VH on Powermatic Associates
Schneider Electric

Part#:QOU160VH

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QOU160VH is a unit-mount Miniature Circuit Breaker (MCB) designed for a single pole configuration. It features slotted box lugs connections on both the load and line sides, accommodating a cross-section of 14-2AWG for one aluminum or copper cable. This MCB is rated for a current of 60A and supports rated voltages of 120V and 240V AC, with a short circuit breaking rating of 22kA at 240Vac and 5kA at 48Vdc. The terminals are of the box lugs type, facilitating secure and straightforward installation.

Product Details

  • [Ue] Rated Operational Voltage
    120/240 V AC
  • Tightening Torque
    45 lbf.in (5.08 N.m) (AWG 14...AWG 2)
  • Mounting Mode
    Unit mount
  • Line Rated Current
    60 A
  • Depth
    2.95 in (74.93 mm)
  • AWG Gauge
    AWG 14...AWG 2 aluminium/copper
  • Height
    4.05 in (102.87 mm)
  • Circuit Breaker Type
    Standard
  • Range Of Product
    QOU
  • Width
    0.75 in (19.05 mm)
  • Product Or Component Type
    Miniature circuit-breaker
  • Electrical Connection
    Slotted box lugs, line side Slotted box lugs, load side

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOU160VH on Powermatic Associates is $101.00. Order now.
