QOW115 Schneider Electric Industrial Automation Components

QOW115 on Powermatic Associates
Schneider Electric

Part#:QOW115

Manufacturer:Schneider Electric

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Square D by Schneider Electric QOW115 is a Miniature Circuit Breaker (MCB) designed for plug-in mounting. It features a plug-in connection type and is suitable for a single pole configuration. This MCB is rated for a current of 15A and can accommodate wire sizes from 14-8AWG for both aluminum and copper cables. It is designed to operate at a rated voltage of 120V to 240V AC and 48V DC, with a short circuit breaking rating of 10kA at 240V AC and 5kA at 48V DC. The QOW115 utilizes press plate type terminals for secure wire connections.

Product Details

  • Interrupt Rating
    10 kA 120/240 V AC 50/60 Hz 10 kA 120 V AC 50/60 Hz 5 kA 48 V DC
  • Voltage Rating
    120/240 V AC 120 V AC 48 V DC
  • Depth
    2.91 in (73.91 mm)
  • Tightening Torque
    44.25 lbf.in (5 N.m) 0.02…0.04 in² (10…25 mm²) (AWG 8...AWG 2)
  • Number Of Panel Spaces
    1
  • Wire Size
    AWG 14...AWG 8 copper or aluminium
  • Electrical Connection
    Pressure plate
  • Height
    3 in (76.20 mm)
  • Width
    0.75 in (19.05 mm)
  • Circuit Breaker Type
    Standard
  • Mounting Type
    Plug-in
  • Number Of Poles
    1P
  • Ratings
    HACR and Switching Duty rated
  • Current Rating
    15 A
  • Product
    Miniature circuit-breaker
  • Range
    QO

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of QOW115 on Powermatic Associates is $19.20. Order now.
