RXM3AB2FD Schneider Electric Industrial Automation Components

Product Details

• Mechanical Durability
  10000000 cycles
• Rated Operational Voltage Limits
  88...121 V DC
• Status LED
  With
• [Uimp] Rated Impulse Withstand Voltage
  4 kV 1.2/50 µs
• Device Short Name
  RXM
• Range Of Product
  Harmony Electromechanical Relays
• Maximum Switching Voltage
  250 V IEC
• Release Time
  20 ms
• Operating Position
  Any position
• Average Coil Resistance
  13440 Ohm 20 °C +/- 10 %
• Contacts Type And Composition
  3 C/O
• Electrical Durability
  100000 cycles resistive
• Protection Category
  RT I
• Contacts Material
  AgNi
• Utilisation Coefficient
  20 %
• Series Name
  Miniature
• Shape Of Pin
  Flat
• Minimum Switching Capacity
  170 mW 10 mA, 17 V
• Drop-Out Voltage Threshold
  >= 0.1 Uc
• Device Presentation
  Complete product
Product Or Component Type
Plug-in relay
Average Coil Consumption In W
0.9 W
[Ithe] Conventional Enclosed Thermal Current
10 A -40…131 °F (-40…55 °C)
Maximum Switching Capacity
2500 VA/280 W
Control Type
Lockable test button
[Uc] Control Circuit Voltage
110 V DC
Operate Time
20 ms
Net Weight
0.08 lb(US) (0.037 kg)
Test Levels
Level A
CAD Overall Depth
3.16 in (80.35 mm)
Safety Reliability Data
B10d = 100000
CAD Overall Height
3.26 in (82.8 mm)
Resistive Rated Load
10 A 250 V AC 10 A 28 V DC
Operating Rate
<= 1200 cycles/hour under load <= 18000 cycles/hour no-load
[Ui] Rated Insulation Voltage
250 V IEC 300 V CSA 300 V UL
[Ie] Rated Operational Current
10 A 28 V DC) NO IEC 10 A 250 V AC) NO IEC 5 A 28 V DC) NC IEC 5 A 250 V AC) NC IEC 10 A 30 V DC) UL 10 A 277 V AC) UL
