XB5AA65 Schneider Electric Industrial Automation Components
Part#:XB5AA65
Manufacturer:Schneider Electric
Category:Industrial Automation Components
Product Lifecycle:Active
Jul 5, 2025
Product description
Schneider Electric XB5AA65 is a flush push-button designed for various control applications. This component, part of the XB5 range, features a plastic body and bezel with a diameter of 22 mm. It offers a degree of protection rated at IP66, NEMA 4X, and NEMA 13, ensuring its suitability for harsh environments. The push-button is equipped with 1 Normally Open (NO) and 1 Normally Closed (NC) auxiliary contacts, supporting a control circuit rated current of 10 A at 120Vac (AC-15), 6 A at 240Vac (AC-15), 3 A at 600Vac (AC-15), 1.2 A at 125Vdc (DC-13), 0.55 A at 250Vdc (DC-13), and 0.27 A at 600Vdc (DC-13) with a minimum of 0.1 A. It features screw-clamp terminals for secure connections and an operating force of 3.5 N. The XB5AA65 is designed for spring-return (impulse/momentary) operation, has a mechanical durability of 5,000,000 operations at no load, and an electrical durability of 1,000,000 operations with load. It includes short-circuit protection facilitated by a 10A gG cartridge fuse and has a rated impulse voltage (Uimp) of 6 kV.
Product Details
- Type Of Operator spring return
- Operator Profile Blue flush, unmarked
- Tightening Torque 7.08…10.62 lbf.in (0.8…1.2 N.m) EN 60947-1
- Range Of Product Harmony XB5
- Contacts Usage Standard contacts
- Device Short Name XB5
- Positive Opening With conforming to EN/IEC 60947-5-1 appendix K
- Depth 2.05 in (52 mm)
- [Uimp] Rated Impulse Withstand Voltage 6 kV EN/IEC 60947-1
- Mounting Diameter 0.87 in (22 mm)
- [Ith] Conventional Free Air Thermal Current 10 A EN/IEC 60947-5-1
- Compatibility Code XB5
- Shape Of Signaling Unit Head Round
- Fixing Collar Material Plastic
- Width 1.18 in (30 mm)
- Product Or Component Type Push-button
- Contacts Type And Composition 1 NO + 1 NC
- Sale Per Indivisible Quantity 1
- Height 1.65 in (42 mm)
- Mechanical Durability 10000000 cycles
- Customizable 1
- Head Type Standard
- Contact Operation Slow-break
- Contacts Material Silver alloy (Ag/Ni)
- Resistance To High Pressure Washer 1015.26 psi (7000000 Pa) 131 °F (55 °C) 0.1 m
- GCR BRIDGE XB5AACUST04
- Short-Circuit Protection 10 A cartridge fuse gG EN/IEC 60947-5-1
- Device Presentation Complete product
- [Ui] Rated Insulation Voltage 600 V 3)EN/IEC 60947-1
- Electrical Reliability Λ < 10exp(-6) 5 V 1 mA in clean environment EN/IEC 60947-5-4 Λ < 10exp(-8) 17 V 5 mA in clean environment EN/IEC 60947-5-4
- Terminals Description ISO N°1 (21-22)NC (13-14)NO
- Connections - Terminals Screw clamp terminals, <= 2 x 1.5 mm² with cable end EN/IEC 60947-1 Screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end EN/IEC 60947-1
- Bezel Material Plastic Dark grey plastic
- Operating Force 3.5 N NC changing electrical state 3.8 N NO changing electrical state
- Operating Travel 0.06 in (1.5 mm) NC changing electrical state) 0.10 in (2.6 mm) NO changing electrical state) 0.17 in (4.3 mm) total travel)
- Electrical Durability 1000000 cycles AC-15, 2 A 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycles AC-15, 3 A 120 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycles AC-15, 4 A 24 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C 1000000 cycles D
- Shape Of Screw Head Cross compatible with Philips no 1 screwdriver Cross pozidriv No 1 Slotted flat Ø 4 mm Slotted flat Ø 5.5 mm
- [Ie] Rated Operational Current 3 A 240 V, AC-15, A600 EN/IEC 60947-5-1 6 A 120 V, AC-15, A600 EN/IEC 60947-5-1 0.1 A 600 V, DC-13, Q600 EN/IEC 60947-5-1 0.27 A 250 V, DC-13, Q600 EN/IEC 60947-5-1 0.55 A 125 V, DC-13, Q600 EN/IEC 60947-5-1 1.2 A 600 V, AC-15, A6
