BI3U-EM12E-AP6X-H1141 Turck Industrial Automation Components

BI3U-EM12E-AP6X-H1141 on Powermatic Associates
Turck
  • BI3U-EM12E-AP6X-H1141
  • BI3U-EM12E-AP6X-H1141

Part#:BI3U-EM12E-AP6X-H1141

Alt. Part#:1634343

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

BI3U-EM12E-AP6X-H1141 Turck - BI3U-EM12E-AP6X-H1141 Inductive Sensor

Product Details

  • Weight
    31 g
  • Country Of Origin
    DEU
  • HTS Code
    8536507000
  • Rated switching distance
    3 mm
  • Construction size
    M12 x 1
  • Output function
    NO contact, PNP
  • Mounting
    Flush
  • Electrical connection
    Connector, M12 × 1
  • Ambient temperature
    -30…+85 °C
  • Design
    Threaded barrel
  • Housing material
    Stainless steel, 1.4301 (AISI 304)
  • Protection class
    IP68
  • Operating voltage
    10…30 VDC
  • Special features
    uprox+, Factor 1, Resistant to magnetic fields
  • Operating Voltage
    10 volts, 30 volts
  • Ambient Temperature
    -30 degrees celsius, 85 degrees celsius
  • Country of Origin
    Germany
  • Weight
    31 grams

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of BI3U-EM12E-AP6X-H1141 on Powermatic Associates is $155.80. Order now.

About the product

Inductive Sensor, Rated switching distance 3 mm, Flush, Threaded barrel, M12 x 1, Stainless steel, 1.4301, Factor 1 for all metals, Protection class IP68, Resistant to magnetic fields, Extended temperature range, High switching frequency, DC 3-wire, 10…30 VDC, NO contact, PNP output, M12 x 1 male connector
