PS510-400-03-LI2UPN8-H1141 Turck Industrial Automation Components
Part#:PS510-400-03-LI2UPN8-H1141
Alt. Part#:100001591
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
PS510-400-03-LI2UPN8-H1141 Turck - PS510-400-03-LI2UPN8-H1141 Pressure Sensor, Relative Pressure: 0…400 Bar
Product Details
- Weight 283 g
- Country Of Origin POL
- HTS Code 9026204000
- Relative pressure psi 0…5801.51 psi rel.
- Medium temperature -30…+80 °C
- Process connection 1/4” NPT male thread
- Current output 4…20 mA
- Relative pressure bar 0…400 bar rel.
- Electrical connection Connector, M12 × 1
- Electrical output Current output (3-wire), 2 × switching output
- Housing material Stainless-steel/Plastic, 1.4404 (AISI 316L)/Grilamid TR90 UV
- Design With display
- Pressure type Relative pressure
- Communication protocol IO-Link
- Voltage output 0…10 V
- Ambient temperature -40…+80 °C
- Operating voltage 18…33 VDC
- Protection class IP6K6K / 6K7 / 6K9K
- Operating Voltage 18 volts, 33 volts
- Country of Origin Poland
- Weight 283 grams
- Ambient Temperature -40 degrees celsius, 80 degrees celsius
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PS510-400-03-LI2UPN8-H1141 on Powermatic Associates is $485.80. Order now.
About the product
Pressure Sensor, Relative Pressure: 0…400 Bar, , 4-digit, 2-colored, 12-segment display, rotatable by 180°, Housing is rotatable after plugging the process connection, Metal measuring cell, 18…33 VDC, NO/NC contact, PNP/NPN output, analog output (current/voltage), IO-Link, Process connection 1/4" NPT male thread, Connector device, M12 × 1
