PT30PSIG-2014-I2-H1141 Turck Pressure Sensors
Part#:PT30PSIG-2014-I2-H1141
Alt. Part#:6836850
Manufacturer:Turck
Category:Pressure Sensors
Product Lifecycle:Active
Product description
PT30PSIG-2014-I2-H1141 Turck - PT30PSIG-2014-I2-H1141 Pressure Transmitter, With Current Output (2-Wire)
Product Details
- Weight 75 g
- RoHS Yes
- Country Of Origin CHE
- HTS Code 9026204000
- Electrical output Current output (2-wire)
- Relative pressure bar 0…2.07 bar rel.
- Electrical connection Connector, M12 × 1
- Process connection 1/8” NPT male thread
- Operating voltage 7…33 VDC
- Ambient temperature -30…+85 °C
- Pressure type Relative pressure
- Protection class IP67
- Housing material Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyacrylamide 50 % GF UL 94 V-0
- Relative pressure psi 0…30 psi rel.
- Medium temperature -40…+135 °C
- Current output 4…20 mA
- Design Without display
- Pressure transducer material Stainless steel 1.4016 (AISI 430)
- Ambient Temperature -30 degrees celsius, 85 degrees celsius
- Country of Origin Switzerland
- Weight 75 grams
- Operating Voltage 33 volts
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of PT30PSIG-2014-I2-H1141 on Powermatic Associates is $169.30. Order now.
About the product
Pressure Transmitter, With Current Output (2-Wire), , Fully welded metal measuring cell, Pressure range 0…30 psi rel., 7…33 VDC, Analog output 4…20 mA, Process connection 1/8-27 NPT male thread, Plug-in device, M12 × 1, "
