RI-10SA1R-2K1800-7MIL/N29 Turck Industrial Automation Components
Part#:RI-10SA1R-2K1800-7MIL/N29
Manufacturer:Turck
Category:Industrial Automation Components
Product Lifecycle:Discontinued
Product description
RI-10SA1R-2K1800-7MIL/N29 Turck - RI-10SA1R-2K1800-7MIL/N29 Incremental Shaft Encoder, Industrial Line
Product Details
- Resolution, incremental 1800 ppr
- Encoder line Industrial-Line
- Electrical connection Connector
- Technology Optical
- Housing material Die-cast zinc
- Output type Incremental
- Protection class shaft IP67
- Flange diameter Ø 63.5 mm
- Ambient temperature -40…+85 °C
- Operating voltage 5…30 VDC
- Output function Push-Pull 7272, with inverted signals
- Flange type Rectangular flange
- Shaft Type Solid shaft
- Protection class IP67
- Operating Voltage 30 volts
- Ambient Temperature -40 degrees celsius, 85 degrees celsius
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Incremental Shaft Encoder, Industrial Line, Resolution, incremental 1800 ppr, Square flange, Ø 63.5 mm, Solid shaft, Ø 3/8” x 7/8”, Optical measuring principle, Shaft material, stainless steel, , Protection class IP67 on housing and shaft side, ‐40…+85 °C, Max. 6000 rpm (continuous operation 3000 rpm), 5…30 VDC, Male connector MIL, 7-pole, Push-pull 7272, with inverted signals, Pulse frequency max. 300 kHz, , 1800 pulses
