RI360P1-QR14-ESG25X2 Turck Industrial Automation Components

RI360P1-QR14-ESG25X2 on Powermatic Associates
Turck

Part#:RI360P1-QR14-ESG25X2

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Discontinued

Get a quick Quote!

RI360P1-QR14-ESG25X2 Inductive Angle Sensor, Premium Line

About the manufacturer: Turck is one of the manufacturers that offers Industrial Automation Components that you can order at Powermatic Associates site. Turck is a leading provider of sensor, fieldbus, and connectivity technologies, along with interface technology, human-machine interfaces (HMI), and RFID systems. We offer innovative solutions for factory and process automation requirements, guaranteeing top-notch performance.

Check out the RI360P1-QR14-ESG25X2 Turck price in the box on the right side or send a quick quote.

Product Details

  • Cable length (L)
    2.0  m
  • Protection class
    IP68/IP69K
  • Communication protocol
    SSi
  • Electrical connection
    Cable
  • Housing material
    Plastic, PBT-GF30-V0
  • Ambient temperature
    -25…+70 °C
  • Operating voltage
    15…30 VDC
  • Measuring range
    0…360°
  • Flange type
    Flange without mounting element
  • Encoder line
    Premium-Line
  • Construction size
    53.5 x 49 x 14 mm
  • Shaft diameter D [mm]
    6  mm6.35  mm
  • Output type
    Absolute singleturn
  • Shaft Type
    Blind hole shaft
  • Technology
    Contactless

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


RI360P1-QR14-ESG25X2 Description

Inductive Angle Sensor, Premium Line, Cable length (L) 2 m, Rectangular, plastic, Many mounting possibilities, P1-Ri-QR14 included in delivery, Measuring range displayed via LED, Immune to electromagnetic interference, Resolution, 16-bit, 15…30 VDC, Cable connection, 8-pin, SSI output, 25 bit, Gray-coded, 62.5 kHz … 1 MHz



Related documents RI360P1-QR14-ESG25X2 Specs

Manufacturer warranty
