TBEN-LL-4RFID-8DXP Turck Industrial Automation Components

TBEN-LL-4RFID-8DXP on Powermatic Associates
Turck
  • TBEN-LL-4RFID-8DXP
  • TBEN-LL-4RFID-8DXP

Part#:TBEN-LL-4RFID-8DXP

Alt. Part#:100002463

Manufacturer:Turck

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

TBEN-LL-4RFID-8DXP Turck - TBEN-LL-4RFID-8DXP Compact Multiprotocol RFID Module for Ethernet, 4 RFID Channels (HF/UHF) and 8 Universal Digital Channels, Configurable as PNP Inputs or 2-A Outputs

Product Details

  • Weight
    565 g
  • Country Of Origin
    DEU
  • HTS Code
    8536507000
  • Protection class
    IP65/IP67/IP69K
  • Ambient temperature
    -40…+70 °C
  • Number of channels
    12
  • Fieldbus Protocol
    Modbus TCP, EtherNet/IP, PROFINET
  • Ambient Temperature
    -40 degrees celsius, 70 degrees celsius
  • Country of Origin
    Germany
  • Weight
    565 grams

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TBEN-LL-4RFID-8DXP on Powermatic Associates is $1,614.30. Order now.

About the product

Compact Multiprotocol RFID Module for Ethernet, 4 RFID Channels (HF/UHF) and 8 Universal Digital Channels, Configurable as PNP Inputs or 2-A Outputs, Cable length (L) 50 m, PROFINET device, EtherNet/IP device or Modbus TCP slave, PROFINET S2 system redundancy, Integrated Ethernet switch, Supports 10 Mbps/100 Mbps, Glass fiber reinforced housing, Shock and vibration tested, Fully potted module electronics, Protection classes IP65, IP67, IP69K, M12, L-coded connector for power supply, ATEX Zone 2/22, Up to 128 bytes of user data (EtherNet/IP: up to 80 bytes) per read/write cycle per channel and use of fragments with 16 kilobytes of FIFO memory each, Data interface for convenient use of the RFID functions, Continuous HF bus mode with up to 32 HF read/write heads per channel, 4 channels with M12 connection for RFID, 8 universal digital channels, configurable as PNP inputs or 2 A outputs, Programmable ARGEE

TBEN-LL-4RFID-8DXP Related Documents

English-1630966907239.pdf
